DIMENSIONS et PRINCIPALES PIÈCES

Dimensions



40" 9/16

22" 1/16

-

26" 6/16

9" 7/16

23/32"

29" 29/32 - 35" 11/32

5" 29/32

3" 15/16

Composantes

Ref. Qté Pièces du produit

11 Corps de la hotte équipé de : commandes, lumière, groupe ventilateur, filtres

2

1

Cheminée télescopique formée de :

2.1

1

Cheminée supérieure

2.2

1

Cheminée inférieure

10

1

Clapet anti-reflux

15

1

Raccord de sortie d’air

Ref.

Qté

Pièces servant à l’installation

7.1

2

Brides de montage de la hotte

7.2.1

1

Brides de montage de la cheminée supérieure

7.3

1

Bride de raccord de sortie d’air

11

8

Chevilles (si fournies)

12a

8

Vis 3/16” x 1” 3/4

12c

6

Vis 1/8” x 3/8”

12d

2

Vis 3/16” x 1”

12e

2

Vis 1/8” x 1/2“



Qté

Documentation



1

Manuel d’instructions

FR

9" 1/32

14" 5/32

27/32 - 19" 21/32









18"









7.3

11



15



12a



















12e











7.2.1







12c



2.1





2





12c









2.2





10















12c









12a

11



1





7.1









12d









1









19
