C H A P T E R 12

Field-Replaceable Unit Guide

Revised: July 28, 2008, OL-14521-01

This chapter describes the steps you perform to replace the field-replaceable units (FRUs) for the Cisco TelePresence system and includes the following sections:

•Powering On the System, page 12-1

•Replacing the Camera Cluster—Part Number CTS3K-CAM-CLST-G2, page 12-2

•Replacing a Plasma Display—Part Number CTS-DISP-65-GEN2, page 12-4

•Replacing a Speaker—Part Number CTS-LDSPKR, page 12-8

•Replacing a Codec Unit—Part Number CTS-CODEC-PRI-G2 (Primary Codec) or CTS-CODEC-SEC (Secondary Codec), page 12-10

•Replacing a Microphone—Part Number CTS-MIC, page 12-12

•Replacing a Light Fixture—Part Number CTS-LIGHT-FIXT, page 12-14

•Replacing the Audio/Video Extension Unit—Part Number CTS-AV-EXP, page 12-15

•Replacing the Auxiliary Control Unit—Part Number CTS-LIGHT-CTRL, page 12-16

•Replacing the Cisco Unified IP Phone—Part Number CP-7975G-CTS, page 12-17

•Replacing the Projector Lamp—Part Number CTS-PRJTR-BL-GEN1, page 12-17

•Replacing the Projector—Part Number CTS-PRJTR-GEN1, page 12-18

•Replacing a PDU—Part Number CTS-PWR-PDU, page 12-19

•Replacing a Display Shelf, page 12-20

•Replacing a First Row Table Top Section, page 12-22

•Replacing a Second Row Table Top Section, page 12-24

Powering On the System

Use this procedure for sections in this chapter that require you to power on the system.

Step 1 If you replaced the primary codec, reconfigure the codec for the new MAC address in Cisco Unified Communications Manager by performing the following actions:

a.Log in to Cisco Unified Communications Manager.





Cisco TelePresence System 3200















OL-14521-01





12-1











Page 196 Page 198
Page 197
Image 197
Cisco Systems 3200 manual Field-Replaceable Unit Guide, Powering On the System, 12-1
