SAMSUNG DVM-Pro 2008 User Guide

6-2-5. Viewing Diagram

-. Full size : View the diagram on a large scale.

-. Vertical : View the vertical diagram after check [vertical]. 6-2-6. Input Pipe length

[Input Pipe length] shows if presses a right mouse on Ref Joint that is blue triangle part of piping system diagram or Indoor unit.

can input length of each piping, and give an effect to [check system] if the length is inputted.

6-2-7. Check System

Examine piping connection state, Pipe length, the difference between floors and etc. -. If press [Check system], it’s opened window of [Check system].

21
