OPTIONAL PARTS

For Model: SF110AXSQ1 (Designer White)

Illus. Part

No. No. DESCRIPTION

Following Parts Not Illustrated

SPLICING WIRES−−25FT.

LENGTH

242828

Wire, Black



12

Ga. 150 c

8316781

Wire, Black



14

Ga. 150 c

242821

Wire, Blue



14

Ga. 150 c

242822

Wire, Brown



14

Ga. 150 c

242830

Wire, Brown



14

Ga. 200 c

242823

Wire, Green



14

Ga. 150 c

242824

Wire, Orange



14

Ga. 150 c

242825

Wire, Red



14

Ga. 150 c

242831

Wire, Red



14

Ga. 200 c

242827

Wire, Yellow



14

Ga. 150 c

Illus. Part

No. No. DESCRIPTION

REFINISHING MATERIAL

799832 Kit, Porcelain

Repair (White)

242756 Touch−Up

Self−Clean(1/2 Pt)

261582 Grease

INSULATION

261514 Insulation,

Fiberglass (1−1/2"

x 24" x 120")

240132 Insulation,

Fiberglass (2−1/2"

x 22" x 120")

PAINT, TOUCH−UP (1/2oz.)

72017 White

4392899 Biscuit

511873 White Porcelain

(2 Oz.)

Illus. Part

No. No. DESCRIPTION

WIRING HARNESS PARTS

6610434 Harness, Main

3196696 Clip, Wire

3391018 Cable Tie−Push Mnt

98015022 Bushing, Snap (2)

98005894 Clamp, Cord

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

4392901 Biscuit

285006 Superior Black

206922 Primer (White)

PAINT, BULK (1 qt.)

799344 White (Uncut)

4392900 Biscuit(Uncut)

ANTI−TIP KIT

98017833 Anti−Tip Kit

8191166

9

Page 9
Image 9
