DECLARATION OF CONFORMITY

EC Declaration of Conformity (Only applies to Europe)

We, Husqvarna AB, SE--561 82 Huskvarna, Sweden, Tel: +46--36--146000, as authorised representative in the Community, declare that the leaf blower model McCulloch Mac GBV 345 from serial numbers 2009--031N00001 and onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S DIRECTIVES:

of 22 June 1998 “relating to machinery” 98/37/EC, annex IIA;

of 15 December 2004 “relating to electromagnetic compatibility” 2004/108/EC, and applicable supplements; and

of 8 May 2000 “relating to the noise emissions in the environment” in accordance with Annex V of 2000/14/EC. The measured sound power is 103,9 dB(A), the guaranteed sound power is 108 dB(A). The nominal air flow is 0,142 m3/s.

The following standards have been applied: EN12100-1:2003, EN 12100-2:2003and CISPR 12:2005.

SMP, The Swedish Machinery Testing Institute, Fyrisborgsgatan 3 S--754 50 Uppsala,

Sweden, has carried out voluntary type approval. The certificate(s) are numbered: SEC/07/1219.

09--1--31

Ronnie E. Goldman, Director of Engineering Handheld Consumer Products

TECHNICAL DATA

MODEL: Mac GBV 345



ENGINE



Engine displacement, cm3

25

Maximum Engine Power, according to ISO 8893, kW

0,75

Idle Speed +/-- 400, rpm

3700

Catalytic converter muffler

Yes

WEIGHT



Without tubes, kg

4,4

VOLUME



Fuel tank, cm3

540

SOUND PRESSURE LEVEL



According to ISO 22868



BLOWER



Idling, dB(A)

76,6

Racing, dB(A)

96,7

VACUUM



Idling, dB(A)

81,0

Racing, dB(A)

98,6

SOUND POWER LEVEL



According to ISO 22868



Sound power level, measured dB(A)

103,9

Sound power level, guaranteed LWA dB(A)

108,0

VIBRATIONS



According to ISO 22867



BLOWER



Idling, top handle, m/s2

4,5

Racing, top handle m/s2

13,6

VACUUM



Idling, left/rear handle, m/s2

2,7/2,5

Racing, left/rear handle, m/s2

11,4/14,5

-- 12 --
