Page 33

HYDRO RESERVOIR ASSEMBLY

Item	Part No	Qty	Description	Note
1	7059088	2	ASSY, Hydraulic Tank (Incl. tank, p/n 7074002 & 3 items shown
			below)
2	7075289	1	CAP, Vented	Kelch p/n H4550D
3	7075687	2	GROMMET (Dapco #12078)	was Snapper #7012337
4	7073238	2	FITTING, #8 Elbox (Dapco #12183)
5	7073999	1	BRACKET, R.H. Hydro Tank Mount
6	7074001	1	BRACKET, L.H. Hydro Tank Mount
7	7090548	8	SCREW, 1/4-20 x 1” Hex Head Cap, GR 5 (or 7027230)
8	7091294	16	WASHER, 1/4” Flat
9	7090361	4	SCREW, 5/16-18 x 5/8” Hex Washer Self-Tap
10	7091603	8	NUT, 1/4-20 Hex Nyloc
11	7012080	5	CABLE TIE, 7” Long	not shown

Footnotes:

MID MOUNT Z-RIDER ZERO TURNING		Manual No. 7006938
SERIES 3	33	TP 400-5208-IR-NZ-N
