Snapper RT1330 Pivot, Eccentric, Spindle ASSEMBLY, LH, Tie Rod, Lh, Lever, Spindle ASSEMBLY, RH

Page 11

Steering & Lift Group

Item

Part No

Qty

Description

Note

1

1930645

1

NUT, Hex, 3/8-16



2

2108512

1

PIVOT



3

1708955A

1

ARM ASSEMBLY, Lift



4

1708966

1

GRIP, Lever



5

1708557A

1

LEVER, Lift



6

1708884

1

SPRING, Compression



7

7090122

3

WASHER, Plain, 13/32 x 7/8 x 5/64

Was 1924940

8

1918447

3

COTTER PIN, 3/32 x 3/4



9

1708556

1

CABLE ASSEMBLY, Lift



10

1919439

1

NUT, Hex, Esna Lock, 3/8-16



11

1708559

1

PULLEY, Lift



12

1708973

1

SPACER



13

1924356

1

WASHER, Plain, 13/32 x 1-1/2 x 1/8



14

1921969

1

CAPSCREW, Hex Head, 3/8-16 x 1-1/2



15

1930645

1

NUT, Hex, Flange Lock, 3/8-16



16

1708514

1

ECCENTRIC



17

1922755

1

WASHER, 13/32 x 7/8 x 1/8



18

1921971

1

CAPSCREW, Hex Head, 3/8-16 x 1-3/4



19

1706011

1

SPINDLE ASSEMBLY, LH



20

1935048

3

NUT, Hex, Flange Lock, 5/16-18



21

1960236

2

SPACER



22

1611710

2

KLIP RING



23

1931335

2

CARRIAGE BOLT, 5/16-18 x 1



24

1708501A

1

TIE ROD, LH



25

1919381

1

WASHER



26

1710703

1

SPACER, 21/64 x 1/2 x 5/8



27

7090705

2

WASHER

Was 1960170

28

1708516A

1

LEVER



29

1708521

1

ROD, Hitch



30

1920328

2

CAPSCREW, Hex Head, 1/2-13 x 1-1/2



31

1709237A

1

HITCH, Hook



32

1709235

2

SPACER



33

1930644

2

NUT, Hex, Flange Lock, 1/2-13



34

1706019

1

SPINDLE ASSEMBLY, RH



35

1708500A

1

TIE ROD, RH



Footnotes:

REAR ENGINE RIDER



Manual No. 7006455

SERIES 0

11

TP 400-5021-1-RE-N
