Page 5

QuickSpecs

HP Compaq nc6400 Notebook PC

Standard Features

Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Integrated Bluetooth is also an option (factory configurable only) and can be combined with any of the supported wireless LAN and wireless WAN options.

HP ev2200 1xEV-DO

Integrated dual band 800-MHz (cellular) and 1900-MHz (PCS) WWAN

Broadband Wireless

module connects to the Verizon Wireless BroadbandAccess and

Module*

NationalAccess networks (US only)



Supports CDMA 1xEV-DO, 1xRTT connections



NOTE: Separately purchased Verizon Wireless service is required. For



details, go to http://www.hp.com/go/broadbandwireless.



Upgradeable design and two 800/900/1800/1900/2100-MHz antennas



integrated in the top of the display panel support current and future



WWAN technologies

HP hs2300 HSDPA

Integrated WWAN module that provides connection to GSM, GPRS,

Broadband Wireless

EDGE, UMTS, and HSDPA mobile networks in many countries.

Module*

Currently supported networks are the Cingular network in the U.S. and



Vodafone networks in Australia, France, Italy, Germany, Netherlands,



New Zealand, Spain, and UK, and roaming on Vodafone and partner



networks in more than 60 countries.



NOTE: Separately purchased mobile network operator service is



required.



Upgradeable design and two 800/900/1800/1900/2100-MHz antennas



integrated in the top of the display panel support current and future



WWAN technologies.

All integrated wireless

Wi-Fi certified

LAN options

Cisco Compatible Extensions support (Version 3.0)



Wired Equivalent Privacy (WEP) support up to 128-bit keys



Wi-Fi Protected Access (WPA) and WPA2 support



802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-



GTC, PEAP-MSCHAPv2, and LEAP



Advanced Encryption Standard (AES) support



WiFi certified for WPA2, WMM



Dual antennas integrated in the display enclosure

Intel PRO/Wireless

Intel Centrino mobile technology

3945ABG Network

Integrated support for 802.11a, b and g

Connection

Up to 54-mbps data rate

Intel PRO/Wireless

Intel Centrino mobile technology

3945BG Network

Integrated support for 802.11 b and g

Connection

Up to 54-mbps data rate

Broadcom 4311AG

Integrated support for 802.11a, b and g

WiFi Adapter

Up to 54-mbps data rate

Broadcom 4311BG

Integrated support for 802.11 b and g

WiFi Adapter

Up to 54-mbps data rate

HP Integrated Module

Bluetooth Specification v2.0 compliant

with Bluetooth 2.0

Works with a wide range of Bluetooth devices

Wireless Technology



*Broadband Wireless Module (WWAN) requires Microsoft Windows XP Professional and is available in select countries as a standard feature or as an option to be added later.

DA - 12446 Worldwide QuickSpecs — Version 15 — 1.30.2007

Page 5
