Regulatory Information

Model ID: 200AW8

Model No: HWS8200Q

CE Declaration of Conformity

Philips Consumer Electronics declare under our responsibility that the product is in conformity with the following standards

-EN60950-1:2001 (Safety requirement of Information Technology Equipment)

-EN55022:1998 (Radio Disturbance requirement of Information Technology Equipment)

-EN55024:1998 (Immunity requirement of Information Technology Equipment)

-EN61000-3-2:2000 (Limits for Harmonic Current Emission)

-EN61000-3-3:1995 (Limitation of Voltage Fluctuation and Flicker)

following provisions of directives applicable

-73/23/EEC (Low Voltage Directive)

-89/336/EEC (EMC Directive)

-93/68/EEC (Amendment of EMC and Low Voltage Directive)

and is produced by a manufacturing organization on ISO9000 level.

The product also comply with the following standards

-ISO9241-3, ISO9241-7, ISO9241-8 (Ergonomic requirement for CRT Monitor)

-ISO13406-2 (Ergonomic requirement for Flat Panel Display)

-GS EK1-2000 (GS specification)

-prEN50279:1998 (Low Frequency Electric and Magnetic fields for Visual Display)

-MPR-II (MPR:1990:8/1990:10 Low Frequency Electric and Magnetic fields)

-TCO'99, TCO'03 (Requirement for Environment Labelling of Ergonomics, Energy, Ecology and Emission, TCO: Swedish Confederation of Professional Employees) for TCO versions

RETURN TO TOP OF THE PAGE

Energy Star Declaration

This monitor is equipped with a function for saving energy which supports the VESA Display Power Management Signaling (DPMS) standard. This means that the monitor must be connected to a computer which supports VESA DPMS. Time settings are adjusted from the system unit by software.

NUTEK

VESA State

LED Indicator

Power Consumption

Normal operation

ON (Active)

Green

< 47W (TYP)

Power Saving







Alternative 2

OFF (Sleep)

Amber

< 1 W

One step









Switch Off

OFF

< 1 W
