Obtaining Documentation

No Active Layer 3 Call(s)

Activated dsl 0 CCBs = 0

Output 2 Example (debug ppp negotiation and debug ppp authentication)

pico#ping 192.9.198.1

Type escape sequence to abort.

Sending 5, 100-byte ICMP Echos to 192.9.198.1, timeout is 2 seconds: %LINK-3-UPDOWN: Interface BRI0: B-Channel 1, changed state to up %LINK-5-CHANGED: Interface BRI0: B-Channel 1, changed state to up ppp: sending CONFREQ, type = 3 (CI_AUTHTYPE), value = C223/5

ppp:sending CONFREQ, type = 5 (CI_MAGICNUMBER), value = 28CEEF99

ppp:received config for type = 3 (AUTHTYPE) value = C223 value = 5

acked

ppp:received config for type = 5 (MAGICNUMBER) value = 1E23F5C acked PPP BRI0: B-Channel 1: state = ACKSENT fsm_rconfack(C021): rcvd id E4

ppp:config ACK received, type. = 3 (CI_AUTHTYPE), value = C223

ppp:config ACK received, type = 5 (CI_MAGICNUMBER), value = 28CEEF99 BRI0: B-Channel 1: PPP AUTH CHAP input code = 1 id = 82 len = 16 BRI0: B-Channel 1: PPP AUTH CHAP input code = 2 id = 95 len = 28 BRI0: B-Channel 1: PPP AUTH CHAP input code = 4 id = 82 len = 21 BRI0: B-Channel 1: Failed CHAP authentication with remote.

Remote message is: MD compare failed

ppp:sending CONFREQ, type = 3 (CI_AUTHTYPE), value = C223/5

ppp:sending CONFREQ, type = 5 (CI_MAGICNUMBER), value = 28CEEFDB %LINK-3-UPDOWN: Interface BRI0: B-Channel 1, changed state to down %LINK-5-CHANGED: Interface BRI0: B-Channel 1, changed state to down %LINK-3-UPDOWN: Interface BRI0: B-Channel 1, changed state to up %LINK-5-CHANGED: Interface BRI0: B-Channel 1, changed state to up

ppp:sending CONFREQ, type = 3 (CI_AUTHTYPE), value = C223/5

ppp:sending CONFREQ, type = 5 (CI_MAGICNUMBER), value = 28CEF76C

ppp:received config for type = 3 (AUTHTYPE) value = C223 value = 5

acked

ppp:received conf.ig for type = 5 (MAGICNUMBER) value = 1E24718 acked PPP BRI0: B-Channel 1: state = ACKSENT fsm_rconfack(C021): rcvd id E6

ppp:config ACK received, type = 3 (CI_AUTHTYPE), value = C223

ppp:config ACK received, type = 5 (CI_MAGICNUMBER), value = 28CEF76C BRI0: B-Channel 1: PPP AUTH CHAP input code = 1 id = 83 len = 16 BRI0: B-Channel 1: PPP AUTH CHAP input code = 2 id = 96 len = 28 BRI0: B-Channel 1: PPP AUTH CHAP input code = 4 id = 83 len = 21 BRI0: B-Channel 1: Failed CHAP authentication with remote.

Remote message is: MD compare failed

Obtaining Documentation

Cisco documentation and additional literature are available on Cisco.com. Cisco also provides several ways to obtain technical assistance and other technical resources. These sections explain how to obtain technical information from Cisco Systems.

Cisco.com

You can access the most current Cisco documentation at this URL:

http://www.cisco.com/univercd/home/home.htm

Installing and Configuring Cisco 802 IDSL and Cisco 804 IDSL Routers

18

78-10368-03
