Chapter 4: Troubleshooting

4.3 USING THE LCD

The NBR-420 and NBR-620 are equipped with a front panel LCD as shown in Figure 4-2. The LCD provides network statistics and diagnostic information such as Power up diagnostics, Revision levels, MAC and IP Addresses, and Error Alerts.

RESET

Button LCD

NBR-620MULTI PORT BRIDGE ROUTER WITH LANVIEW®







RECEIVE







TRANSMIT





PWR

COLLISION







DISPLAY RESET



CPU

STAND BY





COM 2

COM 1



D C B A PORT

DISPLAY





1092_04

Button







Figure 4-2

The LCD

Five types of messages appear on the LCD:

Unsaved Initialization messages

Static System messages

Alarm messages

Saved System messages

Failure or Error messages

Sections 4.3.1 through 4.3.5 describe each type of LCD message and provide instructions for displaying them.

Page 4-6

NBR-SERIES Installation Guide
