On Screen Display(OSD) Selection and Adjustment

You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu.

Press the MENU Button, then the main menu of the OSD appears.

Main Menu

MENU : Exit

: Adjust (Decrease/Increase)

SET : Enter

: Select another sub-menu

: Restart to select sub-menu

Menu Name

Icons

NOTE

Button

Tip

Sub- menus

OSD (On Screen Display) menu languages on the monitor may differ from the manual.

16
