Hasselblad 949 manual Troubleshooting, Problem I am not able to mount the Feeder to my scanner

Page 28

28

Troubleshooting

Below are a few common problems and how to solve them.

Problem: I am not able to mount the Feeder to my scanner.

Solution: First, make sure you are using the latest version of FlexColor. Then, use the software-guided procedure for mounting the Feeder as described in “Mounting the Feeder” on page 8.

Problem: The Feeder is not recognized by the scanner or FlexColor software.

Solution: The electronic connection between the scanner and Feeder is probably not secure enough. Gently, but firmly, press the Feeder down against the scanner. When the connection is good and the scanner is turned on, the diodes on the front of the Feeder will light. See also “Mounting the Feeder” on page 8.

Problem: I get an error message that says that the “Feeder cannot find the magazine position.”

Solution 1: Make sure that the magazine is pressed fully into the drawer hinge. (See also “Loading Slides” on page 18.)

Solution 2: Move the magazine to its home position. To do this, run FlexColor and select Maintenance > Feeder to open the Feeder window. Then set the Feeder position drop-down list to “home”. Try scanning again.

Problem: I get an error message that says that the “Feeder cannot find the frame position.”

Solution 1: Check that the holder is mounted correctly. It should be perfectly straight (not angled to either side) and be pressed into the scanner so that it is held by the clasp on the virtual drum (it can sometimes get caught on the front edge of the clasp instead of sliding into it). See also “Mounting the Feeder” on page 8.

Image 28
