Samsung HT-TWZ415 user manual SETTINg the DrC Dynamic rANgE COMPrESSION

Page 58

system setup

SETTINg THE AUDIO

Manually Adjusting the Speaker Volume and Balance with the SOUND EDIT Button.

Press the SOUND EDIT button and then press the

Cursor ,button.

Adjusting Front/rear Speaker Balance

`You can select between 00, -06, and OFF.

`The volume decreases as you move closer to –6.

Adjusting Center/rear/Subwoofer Speaker Level

`The volume level can be adjusted in steps from +6dB to –6dB.

`The sound gets louder as you move closer to +6dB and quieter as you get closer to -6dB.

SETTINg THE DrC (DYNAMIC rANgE COMPrESSION)

This feature balances the range between the loudest and quietest sounds. You can use this function to enjoy Dolby Digital sound when watching movies at low volume at night.

1.In Stop mode, press the MENU button.

. Press the Cursor % button to move to Audio and then press the ENTEr button.

3.Press the Cursor % button to move to DrC and then press the ENTEr button.

. Press the Cursor ,to adjust the DrC.

~When the Cursor button is pressed, the effect is greater, and when the Cursor button is pressed, the effect is smaller.

dPress the rETUrN button to return to the previous level.

dPress the EXIT button to exit the setup screen.

MOVE ENTER RETURN EXIT

CHANGE

RETURN

EXIT

5
