Managed Switch	SMC8728L2
	TigerSwitch 1000™ Standalone 28-port 10/100/1000
	Managed Layer 2 Switch with 2 x 10G uplink slots.

OVERVIEW

SMC Networks' TigerSwitch 1000 (SMC8728L2) is a high performance, Layer 2 Standalone managed switch capable of providing gigabit connections to workgroups in a 1U chassis. The TigerSwitch 1000 delivers 24 ports of 10/100/1000 copper gigabit and 4 SFP ports with the option of 2 x 10G uplinks for futureproof connectivity to the rest of the network. The 96Gbps of wirespeed bandwidth is provided by using a single 28 port switch chip solution reducing latency and bottlenecks within the switch, enabling better performance and throughput. The 10G slots provide the capability to add standards based XFP modules for high bandwidth uplinks. The SMC TigerSwitch 1000 is designed to provide industry leading features and management for increasing productivity and to allow for scalability in the future. The management features include seamless configuration through an easy-to-use Web

Interface, Telnet, and SNMP. In addition to management is the full set or layer 2 features such as; LACP for increased bandwidth and port trunking, Spanning Tree for failover protection, QoS is available with 8 queues, VLAN support for segmenting your network, and bandwidth management per port depending on your network needs. The SMC TigerSwitch 1000 supports ACL on all received frames to limit the types of traffic permitted on a network without imposing any penalty on wirespeed traffic throughput. TigerSwitch 1000 is able to deliver the necessary bandwidth and security to the edge of the network, capable of supporting even the toughest applications.

FEATURES	BENEFITS
High-port density and migration protection in a small footprint	Supports 28 Gigabit ports with 2 optional 10G Uplink slots in an
	1RU chassis
QoS	Support eight levels of priority, with weighted fair queuing and
	L2/3/4 IP precedence--ensures smooth transmission of mission
	critical data
VLAN with GVRP and 802.1v	Support VLANs based on frame tags or ports, plus support for
	automatic GVRP LAN registration spanning tree per VLAN--pro-
	vides maximum security and bandwidth efficiency
IGMP Snooping	Only allows IP Multicast traffic transmission to the registered
	members, resulting bandwidth savings--reduce IP multicast traf-
	fic and increase LAN performance
MultiLink Trunking with LACP	Can group links between switches to provide higher
	bandwidth of up to 16Gbps
Comprehensive security support	Currently supports RADIUS, IEEE802.1x, SSH, SSL,TACACS+,
	ACL
Redundant Power Supply	Provides backup power in case of power failure
Jumbo frame support with wire-speed performance up to 13KB	Ideally suited for video-over-IP, storage-over-IP and data ware-
	housing applications
