A flashing green LED indicates that the adapter is sending or receiving data.

Installation

Installation the 10/100Mbps PCI bus Fast Ethernet Card requires Hardware installation first, then BIOS and Software installation.

Step 1, Hardware Installation

1.

2.

3.

4.

5.

Switch off the computer, unplug the power cord, and remove the computer’s cover.

Select an unused PCI bus-master slot (for WoL use a slot PCI 2.2) and remove its protective bracket.

Carefully insert the card and press until all the edge connectors are firmly seated inside the slot. Then, screw the card’s bracket securely into the PC’s chassis

Install the bracket screw, which secures the card to the cinouter chassis.

Replace the computer’s cover and connect the network cable to newly installed network card. Reconnect the computer’s power cord and plug it into the power outlet.

Step 2, BIOS Configuration

Due to a fault in some Plug-n-Play BIOS programs, it happens occasionally that a newly installed adapter is assigned an Interrupt Number which is
