Acer specifications Acer Standard Storage Models, Acer AN1600 Models

Page 17

Acer AN1600 F1 Network Storage System Specifications

Acer Standard Storage Models

Part Number

Acer AN1600 Models



Acer AN1600F1 Xeon E5620, 2x4GB DDR3 Reg, 2 x 300GB SAS, 4 Port 6G SAS RAID controller,



2x720W 80+ Gold PSU, 2x GBit LAN onboard, Acer Smart Manager, UPS Power Cable, no Mouse, no



KB, Rail kit (2U) Included

TS.R760R.015

Acer AN1600F1 Xeon E5620, 2x4GB DDR3 Reg, 12 x 300GB SAS, 16 Port 6G SAS RAID controller,



2x720W 80+ Gold PSU, 2x GBit LAN onboard, Acer Smart Manager, UPS Power Cable, no Mouse, no



KB, Rail kit (2U) Included

TS.R760R.011

Acer AN1600F1 Xeon E5620, 2x4GB DDR3 Reg, 12 x 1TB SATA, 16 Port 6G SAS RAID controller,



2x720W 80+ Gold PSU, 2x GBit LAN onboard, Acer Smart Manager, UPS Power Cable, no Mouse, no



KB, Rail kit (2U) Included

TS.R760R.012

Acer AN1600F1 Xeon E5620, 3x4GB DDR3 Reg, 12 x 600GB SAS, 16 Port 6G SAS RAID controller,



2x720W 80+ Gold PSU, 2x GBit LAN onboard, Acer Smart Manager, UPS Power Cable, no Mouse, no



KB, Rail kit (2U) Included

TS.R760R.013

Acer AN1600F1 Xeon E5620, 3x4GB DDR3 Reg, 12 x 2TB SAS, 16 Port 6G SAS RAID controller,



2x720W 80+ Gold PSU, 2x GBit LAN onboard, Acer Smart Manager, UPS Power Cable, no Mouse, no



KB, Rail kit (2U) Included

TS.R760R.014

Acer Memory



Note: please refer to "Memory Support" Section for details on configuring memory



Acer Registered Memory



Acer 2GB DDR3-1333Registered Memory Kit (1 pc.)

TC.33100.029

Acer 4GB DDR3-1333Registered Memory Kit (1 pc.)

TC.33100.031

Acer 8GB DDR3-1333Registered Memory Kit (1 pc.)

TC.33100.042

Acer Storage



Acer SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives



Acer 250GB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit

TC.32700.068

Acer 500GB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit

TC.32700.066

Acer 1TB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit

TC.32700.064

Acer 2TB 3Gb/s 7.2K 3.5-inch Enterprise SATA HDD Kit

TC.32700.062

Acer SAS Hot Plug LFF (3.5-inch) Enterprise Drives



Acer 300GB 6Gb/s 15K 3.5-inch Enterprise SAS HDD Kit

TC.32700.079

Acer 450GB 6Gb/s 15K 3.5-inch Enterprise SAS HDD Kit

TC.32700.077

Acer 600GB 6Gb/s 15K 3.5-inch Enterprise SAS HDD Kit

TC.32700.075

Acer SAS Storage Controllers



Acer 4-port 6Gb/s SAS RAID Adapter (w/ mSAS-mSAS cable) Kit

TC.32300.028

Acer 8-port 6Gb/s SAS RAID Adapter (w/ mSAS-mSAS cable) Kit

TC.32300.034

Acer 16-port 6Gb/s SAS RAID Adapter (w/ mSAS-mSAS cable) Kit

TC.32300.042

Acer Battery Backup Kit for Cache module in 8port/16port SAS RAID Card

TC.34800.006

Acer Fibre Channel Storage Controllers



Acer 8Gb/s Single Port Fibre Channel HBA Kit

TC.32300.024

Acer 8Gb/s Dual Port Fibre Channel HBA Kit

TC.32300.026

Acer Cable Management Arm (2U/4U) Kit

TC.33700.021

17

Image 17
Contents Product Front view Product inside view AN1600 F1 Product OverviewProduct Rear View Pre-configured ModelsWhats New Standard Features Features and BenefitsMicrosoft Management Console Microsoft iSCSI Software TargetProduct Specifications Management Operating SystemTechnical Specifications Expansion slots ConnectorEmbedded dual-port Network interface Gigabit serverMaximum internal Hard disk drive StorageStorage Maximum CapacityRAID Volume and Setup Layout Dimm slot notation illustrated in table below Memory PopulationDual-processor configuration Single-processor configurationMirroring mode Lockstep modeMemory Identification 100 120 208 200 220 230 240 Power Supply Specification720W Power Supply Memory Hardware Key OptionsService and Support Acer AN1600 Models Acer Standard Storage Models

AN1600 specifications

The Acer AN1600 is an innovative addition to Acer's line of advanced computing solutions, combining sleek design with powerful performance. Designed for professionals and creatives alike, the AN1600 stands out with its robust features tailored to enhance productivity and streamline workflows.

One of the key features of the Acer AN1600 is its dynamic display technology. Equipped with a vivid 16-inch Full HD display, the AN1600 offers crisp visuals and a wide color gamut, making it ideal for graphic design, video editing, and other visual tasks. This high-quality screen is designed to reduce eye strain, incorporating blue light filtering technologies that provide a more comfortable viewing experience during extended usage.

Under the hood, the Acer AN1600 is powered by cutting-edge processors, ensuring that users can tackle even the most demanding applications with ease. With options for Intel's latest multi-core chips, which deliver impressive processing power for both single-threaded and multi-threaded tasks, users can expect seamless multitasking capabilities and efficient performance. The device is also equipped with high-speed SSD storage, resulting in quick boot times and rapid access to files and applications.

Connectivity is a vital aspect of the Acer AN1600. The device includes a comprehensive array of ports, such as USB-C, USB 3.2, and HDMI, facilitating easy connections to various peripherals and external displays. Wireless connectivity options, including Bluetooth and advanced Wi-Fi technologies, ensure that users can stay connected no matter where they are working.

The design of the Acer AN1600 emphasizes both form and function. Its lightweight chassis makes it highly portable, allowing users to easily carry the device between meetings or classes. Additionally, the ergonomic keyboard and touchpad provide a comfortable user experience, while the laptop's cooling system ensures optimal performance without overheating.

Security features are also a priority with the Acer AN1600. Integrated biometric authentication options allow for quick and secure access to the device, protecting sensitive data and enhancing user confidence in their digital environment.

Overall, the Acer AN1600 combines performance, portability, and functionality, making it a top choice for individuals who demand high-quality computing on the go. Whether used for business, creative projects, or everyday tasks, the AN1600 stands ready to meet the challenges of modern computing.
