Operating the Monitor

Dell™ IN1910N Flat Panel Monitor User's Guide

Using the Front Panel Controls

Using the On-Screen Display (OSD) Menu

Setting the Maximum Resolution

Using the Dell Soundbar (Optional)

Using the Tilt

Using the Front Panel

Use the control buttons on the side of the monitor to adjust the characteristics of the image being displayed. As you use these buttons to adjust the controls, an OSD shows the numeric values of the characteristics as they change.

1-2

1

2

3

4

5

Shortcut keys

Preset Modes Select

Brightness/Contrast

OSD Menu

Exit

Power button (with power light indicator)

Use this button for direct access to the control menu that you define in the personalize menu.

*The default settings are Preset Modes Select and Brightness/Contrast Select.

Use this button for different display preset modes on your monitor.

Use this button to access the "Brightness/Contrast" control menu.

Use this button to open the On-Screen Display (OSD). See Using the OSD Menu.

Use this button to exit the OSD menu.

Use the power button to turn the monitor on and off.

The white light indicates that the monitor is on and fully functional. An amber light indicates power save mode.

Using the On-Screen Display (OSD) Menu

NOTE: If you change the settings and then either proceed to another menu, or exit the OSD menu, the monitor automatically saves the changes. The changes are also saved if you change the settings and then wait for the OSD menu to disappear.

1.Press any key to launch the OSD menu and press to display the main menu.

Main Menu for Analog (VGA) Input
