Page 26

Hardware Setup

SY-6BA+

Step 16. Quick BIOS Setup

This Motherboard does not use any hardware jumpers to set the CPU frequency. Instead, CPU settings are software configurable with the BIOS [SOYO COMBO SETUP]. The [SOYO COMBO SETUP] menu combines the main parameters that you need to configure, all in one menu, for a quick setup in BIOS.

After the hardware installation is complete, turn the power switch on, then press the <DEL> key during the system diagnostic checks to enter the Award BIOS Setup program. The CMOS SETUP UTILITY will display on screen. Follow these steps to configure the CPU settings.

1. Select [LOAD SETUP DEFAULT]

Select the “LOAD SETUP DEFAULT” menu and type “Y” at the prompt to load the BIOS optimal setup.

2. Select [STANDARD CMOS SETUP]

Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to “Auto” .

3. Select [SOYO COMBO SETUP]

Move the cursor to the [CPU Frequency] field to set the CPU frequency, as shown in the following display.





ROM PCI/ISA BIOS











SOYO COMBO SETUP









AWARD

INC.





CPU Frequency



: 350Mhz(100*3.5)

CPU Warning Temperature

: Disabled

CPU Host/PCI Clock

: 100/33MHz



System Temp.

: 24°C/75°F

CPU Ratio



: x 3.5



CPU Temperature

: 29°C/84°F

AGP Clock



: Auto



CPUFAN Speed

: 6553 RPM









CHAFAN Speed

: 6553 RPM









: 2.78 V

VTT(V)

: 1.50V









3.31 V

+5 (V)

: 4.97V









.84V

-12 (V)

: -11.45V

CPU Frequency

: 350Mhz(100*3.5)

4.88V





In Suspend

: Enabled

CPU Host/PCI Clock

: 100/33MHz









CPU Ratio

: x 3.5





− ↓ → ← : Select Item

AGP Clock

: Auto









PU/PD/+/- : Modify



Values

(Shift) F2 : Color









BIOS Defaults









F7 : Load Setup Defaults







23









Image 26
