S P E C F I L E

DLP ™ Projectors

PT-DW5100/DW5100L

Specifications

Main Unit
Power supply:	North America:	120 V AC, 50/60 Hz
	Europe:	220–240 V AC, 50/60 Hz
Power consumption:	North America:	770 W (770 VA) (10 W during standby mode with fan stopped)
	Europe:	750 W (790 VA) (15 W during standby mode with fan stopped)
DLP™ chip:	Panel size:	0.65˝ diagonal (15:9 aspect ratio)
	Display method:	DLP™ chip x 1, DLP™ system
	Pixels:	983,040 (1,280 x 768) x 1, total of 983,040 pixels
Lens:	PT-DW5100:	Powered zoom/focus lenses (1.8 – 2.4:1), F 1.7– 2.0, f 25.6–33.8 mm
	PT-DW5100L:	Optional poweredzoom/focus lenses
Lamp:		300 W UHM lamps (x 2) (dual lamp system)
Screen size:		50– 600 inches (50–200 inches with the ET-DLE050 and ET-DLE055),
		15:9 aspect ratio
Brightness* 1 :		5,500 lumens (dual lamp, high power mode)
Center-to-corner uniformity* 1 :		90%
Contrast* 1 :		2,000:1 (full on/full off, contrast mode: high, brightness: 2,750 lumens)
		1,000:1 (full on/full off, contrast mode: normal)
Resolution:		1,280 x 768 pixels
		(1,600 x 1,200 pixels compatible, compression mode)
Scanning frequency:	RGB:	Horizontal: 15–91 kHz, Vertical: 50– 85 Hz,
		Dot clock: 150 MHz or lower
	YPBPR (YCBCR):	480i: fH 15.75 kHz; fV 59.94 Hz, 576i: fH 15.63 kHz; fV 50 Hz,
		480p: fH 31.50 kHz; fV 59.94 Hz, 576p: fH 31.25 kHz; fV 50 Hz,
		720/60p: fH 45 kHz; fV 60 Hz, 720/50p: fH 37.5 kHz; fV 50 Hz,
		1035/60i: fH 33.75 kHz; fV 60 Hz, 1080/60i: fH 33.75 kHz; fV 60 Hz,
		1080/50i: fH 28.13 kHz; fV 50 Hz, 1080/60p: fH 67.5 kHz; fV 60 Hz,
		1080/50p: fH 56.25 kHz; fV 50 Hz
	S-Video/Video:	Horizontal: 15.75/15.63 kHz, Vertical: 50/60 Hz,
		(NTSC, NTSC4.43, PAL, PAL60, PAL-N, PAL-M, SECAM)
Optical axis shift:		Horizontal (manual) and vertical (powered),
		Horizontal: ±10%, vertical: +60%
Keystone correction range:		Vertical: ±30°
Installation:		Ceiling/floor, front/rear
Terminals * 2 :	DVI-D IN:	DVI-D 24-pin x 1, DVI 1.0 compliant, HDCP compatible, for single link
		only
	RGB 1 IN:	BNC x 5
	R, G, B:	G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
		B, R: 0.7 Vp-p, 75 ohms
		HD/VD, SYNC: TTL (positive/negative)
	Y, PB, PR:	Y: 1.0 p-p, 75 ohms (including sync signal), PB/PR: 0.7 Vp-p, 75 ohms
	RGB 2 IN:	D-sub HD 15-pin x 1
	R, G, B:	G: 0.7 Vp-p (G: 1.0 Vp-p for sync on G), 75 ohms,
		B, R: 0.7 Vp-p, 75 ohms
		HD/VD, SYNC: TTL (positive/negative)
	Y, PB, PR:	Y: 1.0 p-p, 75 ohms (including sync signal), PB,/PR: 0.7 Vp-p, 75 ohms
	VIDEO IN:	BNC x 1, 1.0 Vp-p, 75 ohms
	S-VIDEO IN:	Mini DIN 4-pin x 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
	SERIAL IN:	D-sub 9-pin x 1 (RS-232C compliant) for external controller
	SERIAL OUT:	D-sub 9-pin x 1 (RS-232C compliant) for external controller
	REMOTE 1 IN:	M3 jack x 1 for wired remote control or link control
	REMOTE 1 OUT:	M3 jack x 1 for link control
	REMOTE 2 IN:	D-sub 9-pin x 1 for external control (parallel)
	LAN:	RJ-45 x 1, compliant with PJLink™, 10Base-T/100Base-TX
Power cord length:		3.0 m (9´10˝)
Cabinet materials:		Molded plastic

As of January 2009 < 2 >
