Acer Veriton 3300 manual Shift + Windows + M Undo Minimize All

Page 25

15

Item

Component

Description









3

Windows logo key

Start button. Combinations with this







key perform special functions, such as:







Windows + Tab: Activate the next













Taskbar button

Windows + E: Explore My Computer

Windows + F: Find Document

Windows + M: Minimize All

Shift + Windows + M: Undo Minimize All

Windows + R: Display Run dialog box

4

Application key

Opens the applications context menu













(same function as clicking the right













button of the mouse).















5

Cursor keys

Also called arrow keys, let you move the













cursor around the screen. They serve the













same function as the arrow keys on the













numeric pad when the Num lock is













toggled off.















6

Palm rest (detachable)

Provides a comfortable place to rest your













hands while typing.















7

Num lock

When activated, the keypad is set to













numeric mode, i.e., the keys function as













a calculator (complete with arithmetic













operators such as +, -, * and /).















8

Scroll lock

When activated, the screen moves one













line up or down when you press the up













arrow or down arrow respectively. Take













note that Scroll Lock may not work with













some applications.















9

Volume control/Mute

Controls the speaker volume. Turn it













clockwise or counterclockwise to adjust













the volume. Press it to toggle between













mute and sound.
