Samsung XE700T1A-A05US, 700T1AA06 Ports Provided by the Dock, Connecting headphones to the Dock

Page 35

Using the Slate PC Dock

Ports Provided by the Dock

The back of the Dock



1

2

3

4

5













1

DC Jack

A jack to connect the AC adapter that









supplies power to the computer.











2

Wired LAN Port

Connect the Ethernet cable to this port.











Digital Video/

You can connect an HDMI cable to this



Audio Port

3

port. Using this port, you can enjoy digital

(HDMI)



video and audio on the TV.





















You can connect USB devices to the USB











4

USB Port

port such as a keyboard/mouse, digital











camera, etc.





5 Headphone Jack A jack used to connect the headphones.

Using the Slate PC 35

Connecting headphones to the Dock

Using the Headphone jack

1Right-click over the Volume Control icon in the notification area at the bottom right of the Desktop and select Playback Devices. (Alternatively, click the Control Panel > Hardware and Sound > Sound > Playback tab.)

2Select the Speakers(USB audio), click Set Default and click OK.

Using the computer’s built-in speaker when the computer is installing on the Dock

When the Dock is connected, the audio is output to the headphone jack of the Dock. To use the computer’s built-in speaker when the Dock is connected, configure it as follows.

1Right-click over the Volume Control icon in the notifi cation area at the bottom right of the Desktop and select Playback Devices. (Alternatively, click the Control Panel > Hardware and

Sound > Sound > Playback tab.)

2Select the Speakers (Realtek High Defi nition Audio), click Set Default and click OK.
