Fujitsu P50XTA51E SERIES user manual Press Eor Fto select Picture, Press Cor Dto select Tint

Page 19

BASIC PROCEDURE OF ADJUSTMENT MENU OPERATIONS

• Below is shown the basic procedure to make changes to the options in the ADJUSTMENT MENU. (Ex.: adjusting tint setting (Tint))

English

1

Press ;.

The main menu screen will appear.

2

Press Eor Fto select “PICTURE”.

Each time you press Eor F, one of the available



menus appears in the following sequence:



PICTURE POSITION/SIZE AUDIO FEATURES



FACTORY DEFAULT



The PICTURE Menu screen will appear.

3

Press Cor Dto select “Tint”.

4

Press <.

The “Tint” adjustment screen will appear.

“PICTURE” selected in the main menu screen

Italiano Français Español Deutsch





“Tint” selected in the PICTURE





Menu screen

5

Press Eor Fto change tint values.



F: More greenish colors





E: More purplish colors



6

Press <to store.



7

Press ;when you finish.

“Tint” adjustment screen



* Repeat steps 3, 4, 5 and 6 when you wish to make





changes to other options.



* When <is pressed after you have selected “Default”, the settings are returned to those that were valid when you purchased the set.

* Press ;to halt the operation in progress.

Note

On-screen information disappears if you do not take any action for about 60 seconds.

Functions may not be available with some models and some device options.

The adjustment range varies with the display signal. You can adjust the display quality to the value you want within the adjustable range.

Downloaded From TV-Manual.com Manuals

E-19

Póññêèé Português

中文

日 本 語
