Daewoo DTH-14/20V1FSN, Color Television, DTH-14/20V4FSN, DTH-14/20V3FSN manual Service Parts List

Page 34

Service Parts List

CAUTION

“ ® ” Parts recommended for stock.

” Safety critical component, Replace only with genuine Daewoo safety part.



LOC

PART CODE

PART NAME

DESCRIPTION



®

48B4343A01

TRANSMITTER REMOCON

R-43A01 (AA)









PTACPWH403

ACCESSORY AS

DTH-14V4FS























00010

4850A02510

ANT ROD

S3BW216B (L=600 MM)















00030

4850Q00810

BATTERY

R6P/LN















00040

4850A00650

TRANS ANT MATCHING

YSC-T-07 BR















00050

48586003S1

MANUAL INSTRUCTION

SPAIN















M821

4858213800

BAG INSTRUCTION

L.D.P.E T0.05X250X400





PTBCSHH427

COVER BACK AS

DTH-14V1FS























M211

4852151401

COVER BACK

HIPS BK















M211A

4857817640

CLOTH BLACK

FELT 100X20X0.7















M541

4855415800

SPEC PLATE

150ART P/E FILM (C/TV)

















PTPKCPH427

PACKING AS

DTH-14V1FS



















10

6520010100

STAPLE PIN

18M/M J D O















M801

4858038700

BOX CARTON

SW-2 DTQ-1463FW















M811

4858186700

PAD

EPS 14V1















M821

4858210600

BAG P.E

L.D.P.E T0.03X1000X900

















58G0000084

COIL DEGAUSSING

DC-1450













48519A4710

CRT GROUND NET

1401S-1015-1P













PTCACAH529

CABINET AS

DTH-14V1FSN





















®

CRT1

PTRTPWH529

CRT AS

DTH-14V1FSN



V01

58D0000082

COIL DY

ODY-M1489















V02

2233030001

PAINT LOCK

760G















V03

2TC26019BE

TAPE CLOTH

19X30 BEIGE















V04

2224050026

BOND SILICON

RTV 122 CARTRIDGE















V05

4850PM001-

MAGNET CP

NY-225 (MINI NECK)















V06

48A96R004-

RUBBER WEDGE

HMR 28 SR (0X54)















V901

48A96314C5

CRT BARE

A34AGT13X (R)



M191

4851931802

BUTTON CTRL

4939102+5536001





M191A

7178301011

SCREW TAPPTITE

TT2 WAS 3X10 MFZN















M201A

4856013350

SCREW CRT FIXING

25X80 BK













® M201B

4856215402

WASHER RUBBER

CR T2.0

® M201C

4856013351

SCREW CRT FIXING

25X140 YL



M211A

7172401412

SCREW TAPPTITE

TT2 TRS 4X14 MFZN BK















M321

4853214800

BRKT

FR HIPS BK















M491

4854939103

BUTTON

ABS BK















M561

48556136SS

MARK BRAND

SILVER ETCHING DIACUTTIN















M681

4856812001

TIE CABLE

NYLON66 DA100













SP01A

7178301011

SCREW TAPPTITE

TT2 WAS 3X10 MFZN





PTFMSJH427

MASK FRONT AS

DTH-14V1FS

















M201

4852067201

MASK FRONT

HIPS BK













ZZ202

PTSPPWH407

SPEAKER AS

DTQ-14J4FC















PA601

4850703S50

CONNECTOR

YH025-03+35098+ULW=200











®

SP01

4858314010

SPEAKER

SP-5070F01 3W 8 OHM



LOC

PART CODE

PART NAME

DESCRIPTION





®

PTMPMSH529

PCB MAIN MANUAL AS

DTH-14V1FSN























C101

CEXF1H109V

C ELECTRO

50V RSS 1MF (5X11) TP



















C102

CEXF1C101V

C ELECTRO

16V RSS 100MF (6.3X11) TP



















C103

CEXF1H229V

C ELECTRO

50V RSS 2.2MF (5X11) TP



















C104

CMXM2A333J

C MYLAR

100V 0.033MF J (TP)



















C105

CEXF1C471V

C ELECTRO

16V RSS 470MF (10X12.5)TP



















C106

CEXF1H109V

C ELECTRO

50V RSS 1MF (5X11) TP



















C107

CEXF1H228V

C ELECTRO

50V RSS 0.22MF (5X11) TP



















C109

CCZF1H103Z

C CERA

50V F 0.01MF Z



















C110

CCZF1H103Z

C CERA

50V F 0.01MF Z



















C111

CCZF1H103Z

C CERA

50V F 0.01MF Z



















C112

CCZF1H103Z

C CERA

50V F 0.01MF Z



















C113

CCZF1H103Z

C CERA

50V F 0.01MF Z



















C301

CMXM2A103J

C MYLAR

100V 0.01MF J (TP)



















C302

CEXF1H479V

C ELECTRO

50V RSS 4.7MF (5X11) TP



















C303

CEXF1H100V

C ELECTRO

50V RSS 10MF (5X11) TP



















C305

CEXF1H101V

C ELECTRO

50V RSS 100MF (8X11.5) TP



















C307

CXSL2H100D

C CERA

500V SL 10PF D (TAPPING)



















C308

CMXM2A104J

C MYLAR

100V 0.1MF J (TP)



















C310

CEXF1E102C

C ELECTRO

25V RUS 1000MF (13X20) TP



















C311

CEXD1H229Q

C ELECTRO

50V RT 2.2MF (6.3X11) TP



















C401

CCXB2H102K

C CERA

500V B 1000PF K (TAPPING)



















C403

CCYB2H103K

C CERA

500V B 0.01MF K



















C404

CMYH3C722J

C MYLAR

1.6KV BUP 7200PF J



















C405

CEXF2C109V

C ELECTRO

160V RSS 1MF (6.3X11) TP



















C406

CMYE2D514J

C MYLAR

200V PU 0.51MF J



















C410

CEXF2E100V

C ELECTRO

250V RSS 10MF (10X20) TP



















C411

CEXF1H100V

C ELECTRO

50V RSS 10MF (5X11) TP



















C413

CCXB2H102K

C CERA

500V B 1000PF K (TAPPING)



















C414

CEXF1V471V

C ELECTRO

35V RSS 470MF (10X20) TP



















C415

CEXF1C102V

C ELECTRO

16V RSS 1000MF (10X20) TP



















C418

CMXM2A104J

C MYLAR

100V 0.1MF J (TP)



















C419

CBZF1H104Z

C CERA SEMI

50V F 0.1MF Z



















C451

CEXF1C101V

C ELECTRO

16V RSS 100MF (6.3X11) TP



















C452

CEXF1C221V

C ELECTRO

16V RSS 220MF (8X11.5) TP



















C453

CEXF1C101V

C ELECTRO

16V RSS 100MF (6.3X11) TP

















C501

CMXL1J105J

C MYLAR

63V MEU 1MF J

















C502

CEXF1C471V

C ELECTRO

16V RSS 470MF (10X12.5)TP

















C507

CMXM2A224J

C MYLAR

100V 0.22MF J

















C508

CMXM2A224J

C MYLAR

100V 0.22MF J

















C509

CEXF1H229V

C ELECTRO

50V RSS 2.2MF (5X11) TP

















C510

CEXF1C471V

C ELECTRO

16V RSS 470MF (10X12.5)TP

















C511

CMXM2A333J

C MYLAR

100V 0.033MF J (TP)















33
