Watching Videos and DVDs

If you have applicable equipment connected to the TV, you can easily watch videos and DVDs using the TV’s remote control.

Input Select

You can select the external equipment to access.

To operate other manufacturers’ equipment, you need to register the code of the equipment. (p. 39)

With the connected equipment turned On

Display the Input select menu

Select the input mode

Input select





1

TV





2

Component 1

AUX



3

Component 2





4

HDMI 1

GAME

or

5

HDMI 2



select

6

HDMI 3

GAME



7Video 1

8

Video 2

GAME

9

PC

enter



(example)

Press corresponding NUMBER button on the remote control to select the input of your choice.

Select the input of your choice, then press OK.

During the selection, if no action is taken for several seconds, the “Input select” menu disappears.









Terminal

The terminal and label of the

HDMI 1







connected equipment are

GAME





Label









displayed.





















To label each of the inputs,





(example)

please refer to p. 37.

Note

The input label will be displayed on “Input select” screen if Input label is set on p. 37. For side input terminals (HDMI 3/Video 2), “GAME” input label is set as default. (Picture mode is set to “Game”, refer to p. 48.)

For more details for picture mode setting, refer to p.48. For Input label, refer to p. 37.

Press Game to switch to the game screen

Switches to Input terminal that has “GAME” label.

Cycle through the input terminals if there are multiple Input terminals that have “GAME” label. (p. 37)

If there is no Input terminal with “GAME” label, you cannot switch the input terminal to any other input terminal than the one currently selected.

HDMI 1





GAME

HDMI 3



GAME



Video 2



GAME











To return to TV

Note

Select the remote control mode

Press the key to select

Operate the connected equipment, pointing TV’s remote control at the equipment.

(example)

For details, see the manual of the equipment.



VCR MODE

DVD MODE



VCR Record

Record









-

Skip Reverse/



Forward







Rewind/Fast

Reverse/Forward



Forward















VCR MODE

DVD MODE











Stop

Stop

































Pause

Pause

































Play

Play















20

(For other operations, see p. 42)
