Sharp LC 52D85UN, LC 46D85UN Other Viewing Options, Presetting Remote Control Function

Page 34

Other Viewing Options

Presetting Remote Control Function

Operating the Connected Equipment

You can operate the connected AV products (AV receiver, cable box, SAT tuner, DTV, VCR, DVD, LD) using the presetting manufacturer function of your remote control unit.

1

6

2

7

3

8

4

9

10



5





11



12



13



14

Presetting manufacturer codes

1Press FUNCTION until the LED for your device lights up.

2After the LED for your device lights up, press FUNCTION and DISPLAY at the same time to enter the code registration mode. The LED will blink.

3Press 0–9to enter the manufacturer code. (See page 33.)

•Preset mode is fi nished once the LED no longer lights up.

4After registering the code, the LED will stop blinking then turn off after one second. (If you perform an incorrect operation, the LED will blink quickly then turn off.)

To operate the connected equipment, press FUNCTION to select the LED for your device. (VCR, AUDIO, CBL/SAT (cable converter) or DVD.) The LED lights up, and the remote control unit button will function as follows.

•When you operate VCR or DVD, press INPUT to select the terminal connected to your device.

•CABLE and SAT cannot be selected at the same time.

1 SOURCE POWER

• Turns the connected equipment power on and off.

2G

•Rewinds the tape and allows picture search. (VCR)

•Hold down to go in reverse. (DVD)

3REC

•Starts recording. (VCR)

4K

•Pressing quickly once takes you to the start of the chapter currently playing. Each time you press it, you move back to the start of the previous chapter. (DVD)

50–9(CBL/SAT), • (DOT) (SAT)

•Press a button (or buttons) that corresponds to the channel that you wish to watch.

6I

•Starts playback. (VCR, DVD)

7J

•Rapidly advances the tape and allows picture search. (VCR)

•Hold down to fast forward. (DVD)

8F

•Sets pauses and still pictures. (VCR, DVD)

9H

•Stops the tape transport. (VCR)

•Playback stops when pressed. With some DVD players, pressing the button twice may open the disc tray. (DVD)

10L

•Pressing quickly once takes you to the start of the next chapter. Each time you press it, you move ahead to the start of the next chapter. (DVD)

11FLASHBACK

•Press to switch between the current channel and the channel you were watching immediately before. Some manufacturers do not preset FLASHBACK. (CBL)

12CHr/s

•Press CHror CHsto tune in to a higher or lower channel. (CBL)

•Press to select the channel of the TV tuner on the VCR. (VCR)

13MENU

•When this button is pressed, the DVD menu will display.

14a/b/c/d, ENTER

•a/b/c/d: Press the button to select items on the SAT GUIDE screen or SAT MENU screen. (SAT). Press the button to select items on the DVD MENU screen. (DVD)

•ENTER: Press to activate the selected function. (SAT, DVD)

32

Page 33 Page 35
Image 34
Page 33 Page 35
Contents LC-46D85UN LC-52D85UN Page LC-46D85UN LC-52D85UN Model No Serial NoTrademarks Declaration of ConformityAdditional Safety Information Dear Sharp CustomerPrecautions when transporting the TV Tune Into Safety IssueThis Manufacturer Cares Cable clamp Supplied AccessoriesAttaching the Stand Always use the AC cord supplied with the TVUsing the Remote Control Unit Power indicator on the front of the television lights GreenClose the battery cover Installing Batteries in the Remote Control UnitConnecting Antenna Cable PreparationContents TV Rear/Side Part NamesTV Front Input buttonRemote Control Unit When using the remote control unit, point it at the TVWhen using composite cable Input 1 or Connecting to External EquipmentConnecting Audiovisual Equipment When using component cable Input 1 orConnecting a PC Using Digital Audio OutputConnecting Hdmi Equipment When connecting to a PC with an analog RGB terminal InputInitial Setup Turning On/Off the PowerWatching TV Direct Button Operation Changing VolumeSleep Timer Changing ChannelsMTS/SAP stereo mode Digital broadcasting audio modeClosed Captions and Digital Closed Captions Press Power SavingThis will present the Closed Caption information display You can select the screen size Press View ModeFor PC input mode For 43 programsOn-Screen Display Menu For TV/INPUT 1/2/3 ModeFor HDMI/PC-IN Mode Menu ItemsOn-Screen Display Menu Operation Using the remote controlUsing the control panel of the main unit Menu Operation ButtonsOPC Setting Advanced Picture SettingPicture Menu Surround Audio MenuBass Enhancer Power Control Menu Setup MenuFine Sync CH SetupFor automatically adjusting the PC image Input SkipPosition ResetParental Ctrl Parental Control Setting LanguageTV Parental Guidelines When setting an individual content-based rating itemMpaa Voluntary movie rating system RatingCanadian French Ratings How to temporarily release the V-CHIP BlockCanadian English Ratings Reactivating the temporarily released V-CHIP BlockOption Menu Demo Mode Caption SetupFavorite CH Favorite Channel Setting Output SelectSoftware Update Digital Setup MenuAudio Setup IdentificationAfter the screen shown below is displayed, press During the data checking, Checking blinksPress Enter to start updating EnterPresetting Remote Control Function Other Viewing OptionsOther Viewing Options Manufacturer codes Using Aquos Link Controlling Hdmi Equipment Using Aquos LinkOne Touch Recording Aquos Link SetupAuto Power On Selecting RecorderOne Touch Playback Timer RecordingAquos Link Menu Press d to start playing back a titleSound mode changes each time you press Enter Playback of Titles Using Aquos LinkManually Changing Aquos Audio Speaker System’s Sound Mode Selecting Media Type for Aquos Link Compatible RecorderAppendix Setting the TV on the WallRemoving the Stand Troubleshooting-Digital Broadcasting TroubleshootingError message about reception of broadcast RS-232C Port Specifications Model LC-46D85UN Model LC-52D85UN Optional AccessorySpecifications Part name Model numberInformation on the Software License for This Product PC Compatibility ChartClearing the Secret Number Calling for Service Limited WarrantyDimensional Drawings LC-52D85UNSharp Electronics Corporation

LC 46D85UN, LC 52D85UN specifications

The Sharp LC-52D85UN and LC-46D85UN are part of Sharp's AQUOS line, which has made a name for itself with impressive display technology and innovative features. These LCD televisions offer a blend of visual performance, design aesthetics, and user-friendly functionalities, making them suitable for a variety of viewing environments.

One of the standout features of both models is the XLGA (X-Gen LCD panel) technology, which delivers extraordinary picture quality. It enhances color reproduction and sharpness, resulting in stunning visuals. The high dynamic contrast ratio ensures that blacks are deep and rich, while whites remain bright and crisp, creating a more immersive viewing experience.

Moreover, the Sharp LC-52D85UN and LC-46D85UN feature 1080p Full HD resolution. This level of detail allows viewers to enjoy their favorite movies, shows, and games in breathtaking clarity. Coupled with the 120Hz Fine Motion Enhanced technology, these TVs adeptly handle fast-moving images, reducing motion blur for a smoother viewing experience—ideal for sports enthusiasts and action movie lovers.

In terms of connectivity, both models are equipped with an array of inputs, including multiple HDMI ports, component inputs, and composite inputs. This versatility allows users to connect various devices like gaming consoles, Blu-ray players, and sound systems easily. Additionally, the built-in ATSC tuner enables users to access over-the-air HD broadcasts, making these TVs ready for high-definition content without any extra equipment.

The aesthetic design of the LC-52D85UN and LC-46D85UN is another highlight. With a sleek profile and modern bezel, these TVs are attractive additions to any living space. The stands are sturdy and designed to support the larger screen size of the 52-inch model while providing a stylish footprint.

Further enhancing the user experience are Sharp's advanced audio features. Both models come equipped with a powerful audio system, offering clear sound quality to complement the stunning visuals. With features like virtual surround sound, these televisions aim to deliver a well-rounded home entertainment experience.

In summary, the Sharp LC-52D85UN and LC-46D85UN combine cutting-edge display technology, excellent audio quality, and versatile connectivity to cater to all types of viewers. Whether you're watching your favorite films, playing the latest video games, or enjoying sports, these TVs promise to elevate the home viewing experience to new heights.
