13For added protection of the TV set during a lightning storm or when the TV set is to be left unattended for an extended period of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to product due to lightning storms or power line surges.

14A TV set and cart combination should be moved with care. Quick stops, excessive force, and uneven sur- faces may cause the TV set and cart combination to overturn.

SERVICE

15Unplug this TV set from the wall outlet and refer servicing to qualified service per- sonnel under the following conditions:

A.When the power cord or plug is damaged or frayed.

B.If liquid has been spilled into the TV set.

C.If the TV set has been exposed to rain or water.

D.If the TV set does not operate normally by following the operating instructions. Adjust only those controls that are covered in the operating instructions as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV set to normal operation.

E.If the TV set has been dropped or damaged in any way.

F.When the TV set exhibits a distinct change in performance — this indicates a need for service.

16Do not attempt to service this TV set yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

17When replacement parts are required, have the service technician verify in writing that the replacement parts he uses have the same safety characteristics as the orig- inal parts. Use of manufacturer’s specified replacement parts can prevent fire, shock, or other hazards.

18Upon completion of any service or repairs to this TV set, please ask the service techni- cian to perform the safety check described in the manufacturer’s service literature.

19When a TV set reaches the end of its useful life, improper disposal could result in a pic- ture tube implosion. Ask a qualified service technician to dispose of the TV set.

20Note to CATV system installer.

This reminder is provided to call the CATV system installer’s attention to Article 820- 40 of the NEC that provides guidelines for proper grounding and, in particular, spec- ifies that the cable ground shall be connected to the grounding system of the build- ing, as close to the point of cable entry as practical.
