JVC HR-J347EM, LPT0002-0G4A specifications Video Channel Set

Page 5

EN5

Video Channel Set

Video Channel (RF Output Channel) is the channel on which your TV receives picture and sound signals from the video recorder through the RF cable.

2

3

q

5/8

STOP/EJECT

TEST SIGNAL

The channel on which the screen to the left appear clearly in step 3 is your Video Channel.

To view picture signals from the video recorder, set your TV to the Video Channel.

The video recorder is designed to send picture and sound signals via the connected RF cable to your TV on UHF channel 36; if you want to change this Video Channel to another channel between 32 and 40, perform the following steps.

Before starting, make sure of the following:

●The recorder's power should be off.

●No cassette should be inserted in the recorder.

●The connected TV's power should be on.

1



SET TV CHANNEL



Set your TV to a channel between 32 and 40 that you



want to use as the Video Channel on the TV.





BRING TEST SIGNAL ON

2



SCREEN



Hold down the recorder's STOP/EJECT button for more

than 5 seconds.







● Two vertical bars appear on the screen.







3



TUNE YOUR RECORDER



Turn the RF output channel adjustment screw on the



rear panel of the recorder by using a screwdriver until



the two vertical bars become as clear as they can be.





EXIT VIDEO CHANNEL SET

4



MODE



Press the recorder's STOP/EJECT button again to finish



the setting.

Be sure to connect the power plug to an AC outlet first before installing the lithium battery; otherwise, the battery's service life will be drastically shortened.

Installing/Removing the lithium battery

1Make sure that the power plug is connected to an AC outlet and turn off the VCR power.

2Open the battery cover while pressing the release tab as illustrated.

3Insert a lithium battery with the plus (+) side up and push it in.

●To remove the lithium battery, press the latch A down- ward using a pointed non-metallic object, then pull out the lithium battery.

4Close the battery cover until it clicks in place.

A

Page 4 Page 6
Image 5
Page 4 Page 6
Contents HR-J347EM Do not place the recorder Safety PrecautionsBasic Connections Check ContentsSituate Recorder MainsStart Auto SET UP Auto Set UpDuring Auto Set Up Auto Channel SetVideo Channel Set Select Language Select Television System Access Initial SET Screen Access Main Menu ScreenAccess Clock SET Screen Clock SetAccess O.S.D. Screen Access Function SETENABLE/DISABLE On-Screen DisplaysLoad a Cassette Basic PlaybackPoint Start PlaybackPlayback Playback FeaturesActivate HIGH-SPEED Search Activate Repeat Adjust Tracking ManuallyActivate Intelligent PictureSET Counter Memory Activate Index SearchActivate Counter MemoryBasic Recording Recording Features Timer Programming Timer Engage RECORDER’S Timer ModeAuto SP/LP Timer Engage Auto SP/LPAccess Auto Timer Access Function SETAuto Timer Return to NormalCheck And Cancel Programmes Access ProgrammeRevise Programme InformationEdit To Or From Another Video Recorder SET Recording DECK’S Input ModeMake Connections Start Source PlayerEdit From a Camcorder SET RECORDER’S Input ModeStart Camcorder Start RecorderOff-Air Recording Setting Of The Colour System Select ButtonsTape-To-Tape Editing PlaybackRecorded tape HR-J347EM Recorded tape Playback equipmentSelect Auto CH SET Mode Access Tuner SET ScreenSelect TV System Press Push JOGPerform Tuning Access Tuner SETSelect Position Screen Select BandSwap Channel Positions Access Channel ListDelete a Channel FINE-TUNE Fine-Tuning ChannelsTroubleshooting Timer again Timer RecordingQuestions and Answers Index Display Panel Operating JVC TVs Installing BatteriesHow To Use Ions

HR-J347EM, LPT0002-0G4A specifications

The JVC LPT0002-0G4A, known as the HR-J347EM, is a versatile and reliable VCR model designed to cater to the needs of home entertainment enthusiasts. This device combines traditional tape playback capabilities with advanced features, making it a remarkable choice for those who wish to enjoy their favorite VHS tapes with optimal quality and convenience.

One of the standout features of the HR-J347EM is its exceptional video quality enhancement technology. JVC has incorporated their proprietary Digital Noise Reduction (DNR) system into this model, which helps to minimize visual noise and improve overall image clarity during playback. This is particularly beneficial for older tapes that may have accumulated noise over time, allowing users to enjoy a clearer, more vibrant viewing experience.

Another significant aspect of the JVC HR-J347EM is its compatibility with a variety of tape formats. This model supports standard VHS tapes, making it a perfect option for users who have a collection of films, home videos, or other footage stored in this format. The video cassette recorder also allows for easy recording of television programs, ensuring that users can capture their favorite shows with ease.

In terms of design, the JVC HR-J347EM features an intuitive control panel that simplifies operation. Users can easily navigate through options for play, pause, rewind, and fast forward. Additionally, the device is equipped with a remote control, granting convenience and ease of use from a distance. The compact design of the VCR allows it to fit seamlessly into most entertainment setups, whether it be on a shelf or integrated with a home theater system.

Furthermore, the JVC HR-J347EM is engineered with durability and longevity in mind. Built with high-quality components, this VCR is designed to withstand regular use while ensuring reliable performance over time. Its longevity is a key selling point for users who wish to preserve their collection of VHS tapes and continue enjoying them for years to come.

In conclusion, the JVC LPT0002-0G4A, HR-J347EM holds a significant place in the realm of VHS players. With features like Digital Noise Reduction, versatile tape compatibility, user-friendly controls, and sturdy construction, it serves as an excellent device for those looking to relive the nostalgia of home video experiences while enjoying the ease of modern technology. Whether for casual viewing or archiving cherished memories, the HR-J347EM continues to be a valuable addition to any entertainment system.
