JVC HR-VP655U manual Select Auto SP EP Timer SET Mode, Auto SP→EP Timer, Auto Timer

Page 43

Auto SP→EP Timer

If, when recording in SP mode, there is not enough tape to record the entire program, the VCR automatically switches to EP mode to allow complete recording. This feature is especially handy when recording a program of more than 2 hours in length.

For Example . . .

Recording a program of 140 minutes in length onto a 120- minute tape

Approximately 110 minutes Approximately 30 minutes

SP mode



EP mode



Total 140 minutes

Make sure you set "AUTO SP→EP TIMER" to “ON” at the

Function screen before the timer recording starts.



ACCESS MAIN MENU







1

SCREEN









Press MENU.











ACCESS FUNCTION SET







2

SCREEN









Move the highlight bar (arrow) to "FUNCTION SET" by

pressing CH 5° or SHUTTLE PLUS %Þ, then press OK

or SHUTTLE PLUS%.

→





















SELECT AUTO SP EP







3

TIMER SET MODE







Move the highlight bar

FUNCTION







(arrow) to "AUTO SP→EP







AUTO TIMER

OFF

TIMER" by pressing CH

SUPERIMPOSE

ON



5° or SHUTTLE PLUS













=AUTO SP=EP TIMER

ON



%Þ, then press OK or



VIDEO STABILIZER

OFF





SHUTTLE PLUS%to set to

NEXT PAGE









"ON".











SELECT WITH (5,°) AND (OK)

















PRESS (MENU) TO END









RETURN TO NORMAL







4

SCREEN









Press MENU.























NOTES:

●If you have programmed the VCR to timer-record 2 or more

programs, the second program and those thereafter may not fit on the tape if you set the Auto SP→EP Timer mode to "ON". In this case, make sure the mode is not engaged, then set the tape speed manually during timer programming.

●In order to ensure that the recording fits on the tape, this feature may leave a slight non-recorded section at the end of the tape.

●There may be some noise at the point on the tape where the VCR switches from SP to EP mode.

●The Auto SP→EP Timer feature is not available during ITR (Instant Timer Recording), and the feature will work with the

following tapes: T(ST)-30, T(ST)-60, T(ST)-90, and T(ST)-120.

EN43

Auto Timer

When the Auto Timer is set to ON the timer is automatically engaged when the VCR's power is turned off. It is automatically disengaged when the VCR is powered back on.





ACCESS MAIN MENU







1



SCREEN











Press MENU.













ACCESS FUNCTION SET







2



SCREEN











Move the highlight bar (arrow) to "FUNCTION SET" by



pressing CH5° or SHUTTLE PLUS%Þ, then press OK



or SHUTTLE PLUS %.













SELECT AUTO TIMER SET







3



MODE











Move the highlight bar

FUNCTION









(arrow) to "AUTO TIMER"



















by pressing CH5 or



=AUTO TIMER

OFF







SUPERIMPOSE

ON

°





SHUTTLE PLUS%Þ, then

AUTO SP=EP TIMER

OFF



press OK or SHUTTLE

VIDEO STABILIZER

OFF



PLUS%to set to "ON" or

NEXT PAGE









"OFF".











SELECT WITH (5,°) AND (OK)





















PRESS (MENU) TO END



























RETURN TO NORMAL







4



SCREEN











Press MENU.

























NOTE:

For safety, when AUTO TIMER is set to “OFF”, all other VCR functions are disabled while the Timer mode is engaged. To disengage the timer, press TIMER.

Page 42 Page 44
Image 43
