Note: Read entire instruction sheet before you start installation and assembly.

WARNING

Do not begin to install your Peerless product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact your local distributor.

This product should only be installed by someone of good mechanical aptitude, has experience with basic building construction, and fully understands these instructions.

Make sure that the supporting surface will safely support the combined load of the equipment and all attached hardware and components.

Never exceed the Maximum Load Capacity. See page one.

If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of an "edge to edge" stud finder is highly recommended.

Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding power.

This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal injury.

This product was designed to be installed on the following wall construction only;

WALL CONSTRUCTION

HARDWARE REQUIRED

Wood Stud

Included

Wood Beam

Included

Solid Concrete

Included

Cinder Block

Included

Metal Stud

Do not attach except with Peerless Metal Stud Accessory Kit - ACC215;

Brick

Contact Qualified Professional

Other or unsure?

Contact Qualified Professional

Tools Needed for Assembly

stud finder ("edge to edge" stud finder is recommended)

phillips screwdriver

drill

• 5/16" (8 mm) bit for concrete and cinder block wall

• 5/32" (4 mm) bit for wood stud wall

level

Table of Contents

Parts List

3

Installation to Single Wood Stud Wall

4

Installation to Solid Concrete or Cinder Block

5

Attaching Mounting Plate to Screen with VESA Mounting Patterns

6

Installing and Removing Flat Panel Screen

7
