Vizio M501d-A2, M551d-A2, M651d-A2 user manual Professional Picture

Page 31

Adjusting the Professional Picture Settings

Professional Picture Settings allow you to make precise adjustments to the picture and to create picture modes to save groups of picture settings.

The Color Tuner, 11 Point White Balance, and test patterns allow technicians to manually calibrate the TV. Calibration requires specialized training, an input with precisely set colors, and a specialized light meter.

To adjust the professional picture settings:

5

Adjusting the Color Tuner Settings

The Color Tuner settings allow you to adjust the HSB color and 11 point white balance, turn color channels off for testing, and display color bar, flat, and ramp test patterns.

To adjust the HSB color settings:

1.From the PROFESSIONAL PICTURE menu, use the Arrow buttons to highlight Color Tuner, and then press OK. The Color Tuner menu is displayed.

Color Tuner



Red

Green

Blue

Cyan

Magenta

Yellow















Hue

0

0

0

0

25

-14

1.From the PICTURE menu, use the Arrow buttons to highlight Professional Picture, and then press OK. The PROFESSIONAL PICTURE menu is displayed.

2.Use the Arrow buttons to highlight the setting you wish to adjust, then press OK to change the setting:

•Color Tuner - Adjust the HSB color and 11-point white balance, and display calibration test patterns.

•Rename Picture Mode - Rename a custom picture mode.

VIZIO

PROFESSIONAL PICTURE

Color Tuner

Rename Picture Mode

Create Picture Mode

Lock Picture Mode

Delete Picture Mode

Saturation

-1

5

-4

0

-2

0















Brightness

-24

0

-22

0

0

0















Offset

0

0

0





















Gain

0

0

0







2.Use the Arrow buttons on the remote to highlight the Hue, Saturation, Brightness, Offset, or Gain of the color you wish to adjust. Press the OK button.

3.Use the Left/Right Arrow buttons to adjust the value. When you are finished press the OK button to save the setting.

4.When you are finished adjusting the color tuner settings, press the EXIT button.

•Create Picture Mode - Create a custom picture mode.

•Lock Picture Mode - Prevent changes to a custom picture modes.

•Unlock Picture Mode - Allow changes to custom picture modes.

•Delete Picture Mode - Delete a custom picture mode. Inputs assigned to that custom picture mode will be set to Calibrated picture mode.

24
