Samsung DVD-P390 user manual Playing a Disc

Page 14

basic functions

Playing a Disc

Before Play

-Turn on your TV and set it to the correct Video Input by pressing TV/VIDEO button on the TV remote con- trol.

-If you connected an external Audio System, turn on your Audio System and set it to the correct Audio Input.

After plugging in the player, the first time you press the DVD POWER button, this screen comes up: If you want to select a language, press π/button and then press ENTER button. (This screen will only appear when you plug in the player for the first time.)If the language for the startup screen is not set, the settings may change whenever you turn the power on or off. Therefore, make sure that you select the language you want to use. Once you select a menu language, you can change it by pressing the button on the front panel of the unit for more than 5 seconds with no disc in the unit. Then the SELECT MENU LANGUAGE window appears again where you can reset your preferred language.

English

Français

Deutsch

Español

Italiano

Nederlands

Playback

1.Press the OPEN/CLOSE () button.

2.Place a disc gently into the tray with the disc’s label facing up.

3.Press the PLAY/PAUSE () button or OPEN/ CLOSE ( ) button to close the disc tray. When you stop disc play, the player remembers where you stopped, so when you press PLAY/PAUSE () button again, it will pick up where you left off.

4.Stopping Play

Press the STOP () button during play.

5.Removing Disc

Press the OPEN/CLOSE () button.

6.Pausing Play

Press the PLAY/PAUSE () on the remote control during play.

-Screen stops, no sound.

To resume, press the PLAY/PAUSE ( ) button once again.

7.Step Motion Play (Except CD)

Press the SKIP () button on the remote control during PAUSE mode.

-Each time the button is pressed, a new frame will appear.

-No sound is heard during STEP mode.

-Press the PLAY/PAUSE ( ) button to resume normal play.

-You can only perform step motion play in the forward direction.

8.Slow Motion Play

Press the SEARCH ( /) button to choose the play speed between 1/2, 1/4 and 1/8 of normal during PAUSE mode.

-No sound is heard during slow mode.

-Press the PLAY/PAUSE ( ) button to resume normal play.

Note

-If the player is left in the stop mode for more than one minute without any user interaction, a screen saver will be activated. Press the PLAY/PAUSE

() button to resume normal play.

-If the player is left in the stop mode for more than about 30 minutes, the power will automatically shut off.

-If the player is left for about 5 minutes in pause mode, it will stop.

-This ( ) icon indicates an invalid button press.

14_ basic functions
