Samsung AK68-01907A user manual Karaoke functions, Navigating the setup menu

Page 11

-Only CD-R discs with JPEG files in ISO 9660 or Joliet format can be played.

-The name of the JPEG file may not be longer than 8 characters and should contain no blank spaces or special characters (. / = +).

-Only a consecutively written multi-se ssion disc can be played.If there is a blank segment in the multi-session disc, the disc can be played only up to the blank segment.

-A maximum of 500 images can be stored on a single CD.

-Kodak Picture CDs are recommended.

-When playing a Kodak Picture CD, only the JPEG files in the pictures folder can be played.

-Kodak Picture CD: The JPEG files in the pictures folder can be played automatically.

-Konica Picture CD: If you want to see the Picture, select the JPEG files in the clips menu.

-Fuji Picture CD: If you want to see the Picture, select the JPEG files in the clips menu.

-QSS Picture CD: The unit may not play QSS Picture CD.

-If the number of files in 1 Disc is over 500, only 500 JPEG files can be played.

-If the number of folders in 1 Disc is over 500, only JPEG files in 500 folders can be played.

karaoke functions

Karaoke Functions

Operation Sequence

(Only DVD-C450K)

1.Connect the Mixed Audio Out terminals with the TV or Amplifier.

2.Connect Mic into Mic jack. When a MIC is connected, the karaoke functions can be used.

Mic Volume and Key Control

1.Playback the Karaoke Disc containing the wanted songs.

-Press the KARAOKE button to select Mic Volume then press KARAOKE button again to select keycon.

2.Press the /® buttons to change the desired tone.

Note

- If you hear feedback (squealing or howling) while using the karaoke feature, move the micro- phone away from the speakers or turn down the microphone volume or the speaker volume.

-When playing MP3, WMA, DTS and LPCM disc, the karaoke functions will not operate.

-When the MIC is connected, Digital Out does not work.

-The MIC sound outputs only from Analog Audio Out.

Navigating the setup menu

Using the Setup Menu

The Setup menu lets you customize your DVD player by allowing you to select various language preferences, set up a parental level, even adjust the player to the type of television screen you have.

1.With the unit in Stop mode, press the MENU button on the remote control.Use the √/® but- tons to select Setup, then press the or ENTER button.

2.Press the π/† buttons to access the different features. Press the ® or ENTER button to access the sub features.

3.To make the setup screen disappear after setting up, press the MENU button again.

Note

Depending on the disc, some Setup Menu selections may not work.

Setting Up the Language Features

If you set the player menu, disc menu, audio and subtitle language in advance, they will come up automatically every time you watch a movie.

Using the Player Menu Language

1.With the unit in Stop mode, press the MENU button.

2.Press the √/® buttons to select Language Setup Page, then press the or ENTER button.

3.Press the π/† buttons to select the desired language, then press the ® or ENTER button.

Note

-The language is selected and the screen returns to Language Setup menu.

-To make the setup menu disappear, press the MENU button.

- If the selected language is not recorded on the disc, the original pre-recorded language is selected.

-Select “Original” if you want the default soundrack language to be the original languange the disc is recorded in.

-Select “Automatic” if you want the subtitle language to be the same as the language selected as the audio language.

-Some discs may not contain the language you select : in that case the disc will use its original languange setting.

Setting Up the Audio Options

Audio Options allows you to setup the audio device and sound status settings depending on the audio system in use.

1.With the unit in Stop mode, press the MENU button.

2.Press the √/® buttons to select Audio Setup Page, then press the or ENTER button.

3.Press the π/† buttons to select the desired item, then press the ® or ENTER button.

11

Image 11
