Philips DVP3000K/13, SL-0504/13-1 user manual Functional Overview, Front and Rear Panels

Page 10

Functional Overview

E n g l i s h

Front and Rear Panels

STANDBY-ON B

To switch the DVD Player to Standby mode or ON

Disc tray

OPEN/CLOSE /

Open/Close the disc tray

ON LED

LED lights up when the power is on

PLAY LED

LED lights up during playback

T NEXT

– To search or select next chapter or track

IR Sensor

Point the remote control towards this sensor

9 STOP

– To stop playback

2; PLAY

– To start or interrupt playback

PREV S

To search or select previous chapter or track

LEVEL

– Microphone volume control

MIC

– For connecting microphone

Mains (AC Power Cord)

Connect to a standard AC outlet

CVBS (VIDEO Out)

Connect to CVBS Video input of a TV

YPbPr (Component Video Out)

– Connect to YPbPr input of a TV

Audio Out (Left/Right)

Connect to AUDIO inputs of an amplifier, receiver or stereo system

COAXIAL (Digital audio out)

Connect to coaxial AUDIO input of a digital audio equipment

Caution: Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause permanent damage to the unit.

10

01-39 DVP3000K_13 (Korea)

10

25/01/2005, 5:07 PM
