Page 45

REMOTE CONTROL ACCESSORY DEVICE RELATED BUTTONS

When using the TV remote with an acces- sory device, first make certain it is set

to control your accessory device (by the REMOTE CODE or SEARCH method).

1 Set the TV/DVD/ACC mode switch to the proper position on the remote.

2 Point the top of the remote toward the front of the accessory device (remote sensor window) when pressing the buttons.

1

SYSTEM SWITCH

Set in the proper position to send remote commands to the accessory device.

RECORD • BUTTON

Hold the VCR • RECORD button down to begin a VCR recording.

REWIND BUTTON

Press to rewind tapes. For some VCR’s the STOP button may have to be pressed first, then REWIND. May be used to scan back through chapters or titles on DVD movies.

FAST FORWARD BUTTON

Press to rapidly advance a tape or DVD. For some accessory devices, you may need to press the STOP button first, then the FAST FORWARD button. In playback mode hold the button down to view the picture moving rapidly in the forward direction.

TV/VCR BUTTON

Press while in the VCR mode (VCR indi- cator on the front of the unit will light) to view the playback of a tape. Press again to place in the TV position (VCR indicator light will go off) to view one program while recording another program.

When used in the TV mode, the TV/VCR button will will have no functionality.

2



PIP

POSITION

CC

TV

PROG. LIST

CLOCK







DVD







SLEEP

TV/VCR

SOURCE

FORMAT

ACC









A/CH





AUTO

ACTIVE

AUTO

SOUND

CONTROL








SURR.

MENU





SOUND

MUTE

VOL

CH

RADIO

PC TV HD

1 2 3

4 5 6

7 8 9

STATUS/EXITSURF

0

45

POWER BUTTON

Press to turn the accessory device ON and OFF.

PLAY BUTTON

Press to begin playback of a video tape, DVD, etc.

STOP BUTTON ■

Press to stop the motion of a tape or to stop the playback of a DVD.

PAUSE BUTTON II

Press to temporarily stop the tape dur- ing a playback or recording or pause the playback of a DVD. Press again to release Pause.

CHANNEL + & – BUTTONS

Press to scan up or down through the channel numbers if your accessory device will change channels.

NUMBER BUTTON

Press buttons for direct channel selec- tions. May also be used for direct number entries in certain onscreen menu feature settings.

HELPFUL HINT

The buttons on the remote will not operate your accessory device if those features are not found on your accessory’s remote control.

Note: All functions (particularly Search, Rewind, Fast Forward, etc.) will operate the same as with the original remote control pro- vided with your accessory device.
