Apple M9649G/A manual Supporto per il montaggio, Cavo del monitor Viti

Page 14

4Scegliere viti e spessori di protezione adeguati alle dimensioni del monitor ed estrarli dalla confezione in plastica.

5Posizionare gli spessori di protezione su ciascun lato del supporto per il montaggio.

Spessori di protezione

Supporto per il montaggio

6Posizionare il supporto per il montaggio sopra lo slot sulla parte posteriore del monitor come mostrato nell'illustrazione sottostante. Utilizzare la chiave esagonale per fissare il supporto per il montaggio al monitor.

Cavo del monitor

Viti

Supporto per il montaggio

Chiave esagonale

¤

®

7Seguire le istruzioni incluse con la soluzione di montaggio compatibile con lo standard VESA per collegare il monitor al supporto.

8Collegare il cavo di alimentazione CC all'alimentatore e i cavi DVI, USB e FireWire al computer.

14

Italiano
