F U N C T I O N S

			Zoom Lever
	Microphone		Shutter/Macro/Flash Button
			Strap Mount
		LCD Monitor
Flash
	Flash Control Sensor
Self-Timer Lamp
Lens
	A/V OUT (Audio	MENU/OK Button
	visual output)		BACK Button
	Socket
		DISP Button
	DC IN 5V (Power		POWER Button
	Input) Socket	Four-Direction	Handgrip Mount
Battery Cover		Button	Mode Selector
			Switch
	xD-Picture Card/		Speaker

Microdrive™ Slot

USB Socket

Simulated LCD display image

S P E C I F I C A T I O N S

DIGITAL CAMERA FinePix M603

Number of effective pixels* 3.1 million pixels

CCD sensor	1/1.7-inch Super CCD in an interwoven pattern
	(Number of total pixels: 3.3 million pixels

Number of recorded pixels 2832 ⋅ 2128 (6.03 million)/2048 ⋅ 1536/1280 ⋅ 960/640 ⋅ 480 pixels

File format	Still image: JPEG/Movie: AVI (Motion JPEG)
	Design rule for Camera File system compliant/DPOF-compatible
Storage media	Slot No. 1: xD-Picture Card
	Slot No. 2: Microdrive™ (Some CompactFlash™ cards may not work properly)
Number of images/recording time
Modes		Still image				Movie
Image Quality mode displayed	6M (Fine)	6M (Normal)	3M	1M	0.3M	640 (30 frames/sec.)	320 (15 frames/sec.)
Number of recorded pixels	2832 ⋅ 2128		2048 ⋅ 1536	1280 ⋅ 960	640 ⋅ 480	640 ⋅ 480	320 ⋅ 240
DPC-16 (16MB)	6	13	26	49	122	Approx. 13 sec.	Approx. 52 sec.
DPC-32 (32MB)	13	28	53	99	247	Approx. 27 sec.	Approx. 106 sec.
DPC-64 (64MB)	26	56	107	198	497	Approx. 55 sec.	Approx. 213 sec.
DPC-128 (128MB)	53	113	215	398	997	Approx. 111 sec.	Approx. 7 min.
1GB Microdrive	443	938	1,729	3,285	8,213	Approx. 15 min.	Approx. 58 min.

The numbers of images and recording time will vary slightly depending on the type of the subject.

Accessories included 16MB xD-Picture Card, Li-ion battery NP 60,

AC Power Adapter AC-5VHS/AC-5VS, Hand strap, Handgrip, LCD monitor hood, USB cable, A/V cable

CD-ROM

•USB driver

•FinePixViewer

•Apple QuickTime™5.0

•ImageMixer VCD for FinePix

*Number of effective pixels: The number of pixels on the image sensor which receive input light through the optical lens, and which are effectively reflected

in the final output data of the still image.

** Exif 2.2 is a newly revised digital camera file format that contains a variety of shooting information for optimal printing.

Specifications are subject to change without notice.

O P T I O N A L A C C E S S O R I E S

Lens	Super EBC Fujinon 2✕ zoom lens
Lens focal length	f=8.7mm – 17.4mm (equivalent to 38mm – 76mm on a 35mm camera)
Focus	Autofocus
Focus distance	Normal: 60 cm/2.0ft. to infinity
	Macro: 20 cm – 80 cm/0.7ft. – 2.6ft.
Aperture	F 3.2/4/5.2/6.8/8.8/11
Exposure control	64-zone TTL metering-multi
Exposure modes	Programmed AE
Sensitivity	Equivalent to ISO 160, 200, 400
	800/1600 (only at 1280 ⋅ 960 pixels)
Shutter speed	1/4 – 1/2000 sec.
White balance	Automatic
	Manual (Fine, Shade, Fluorescent light (Daylight), Fluorescent light
	(Warm white), Fluorescent light (Cool white), Incandescent light
Flash	Auto flash using flash control sensor
	Effective range: Wide angle	0.3m – 4.0m/1.0ft. – 13.1ft.
	Telephoto	0.3m – 3.0m/1.0ft. – 9.8ft.
	Flash mode: Auto, Red-eye Reduction, Forced Flash, Suppressed
	Flash, Slow Synchro
Self-timer	Approx.10 sec. delay
LCD monitor	2.5-inch low temperature polysilicon TFT (118,000 pixels)
Video output	NTSC or PAL
Terminal	USB Interface, power-input socket
Power source	NP-60 battery (1035mAh)(included), NP-120 battery (1800mAh)(optional)
	or AC-5V AC adapter (included)
Dimensions	64.5 (W) ⋅ 93.3 (H) ⋅ 31.6 mm (D)/2.5 (W) ⋅ 3.7 (H) ⋅ 1.2 in. (D)
Weight	210g/7.4 oz. (excluding battery)
Camera functions	4.4✕ (640 ⋅ 480 pixels), 2.2✕ (1280 ⋅ 960 pixels),
Digital zoom
	1.4✕ (2048 ⋅ 1536 pixels)
Shooting modes	Normal: Auto, Manual
	Continuous shooting
	1. Top-4 (5 frames/sec., up to 4 frames)
	2. Final-4 (5 frames/sec., up to 4 frames)
	3. Long-period (Max. 1.8 frames/sec., up to 40 frames. Only at 1280 ⋅
	960-pixel mode)
Movie recording	640 ⋅ 480 pixels: 30 frames/sec., Max. approx. 15 min.with 1GB Microdrive™
	640 ⋅ 480 pixels: 15 frames/sec., Max. approx. 30 min. with 1GB Microdrive™
	320 ⋅ 240 pixels: 15 frames/sec., Max. approx. 58 min. with 1GB Microdrive™
	With sound, AVI format (Motion JPEG)
Voice Memo	Up to 30 sec., WAV format
Playback	Single frame (with 4.0✕ Playback zoom), 9 Multi-frame

Microsoft, Windows, and Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

Apple is a registered trademark of Apple Computer Inc.

xD-Picture Card DPC-16 (16MB) DPC-32 (32MB) DPC-64 (64MB)

DPC-128 (128MB)

PC Card Adapter

DPC-AD

Image Memory

Card Reader

DPC-R1

(USB)

CompactFlash™

Card Adapter

DPC-CF

AC Power

Adapter

AC-5VH/5VHS

Rechargeable

Lithium-ion

Battery

NP-120

Battery Charger BC-65

•Charges in approx. 2 hours

•The NP-40 battery adapter is included.

PictureCradle CP-FX603

•DC in

•USB

•Connecter to digital camera

Soft Case

SC-FX603
