Samsung SL620 manual Photo Style Selector

Page 45

Functions ( )

Photo Style Selector

You can add various effects to the image without using image editing software.

Photo Style Selector

BackMove

1.Select the desired Photo style selector by pressing the Left/Right button and press the OK button.

2.Press the Shutter button to take an image.

Style mode	Icon	Description

Normal		No style effect is applied.

Soft		Soft style is applied.

Vivid		Vivid style is applied.

Forest		Forest style is applied.

Retro		Sepia style is applied.

Cool		Cool style is applied.

Calm		Calm style is applied.

Classic		Black & white effect is applied.

Negative		Negative effect is applied.

Custom RGB		Deﬁne an RGB tone to create your own photo style.

Custom colour : You can change the R (Red), G (Green) and B (Blue) values of the image.

BackMove

- Up/Down button : Selects R, G, B

- Left/Right button : Changes the values

BackMove

When picture style is set, face detection is not available. When Soft or Vivid in photo style is set, saturation is not available. When Negative in photo style is set, contrast is not available.

44

Image 45
