TOA Electronics C-CV24-2 NTSC instruction manual Specifications, Optional Products

Page 12

10. SPECIFICATIONS

Model No.

C-CV24-2 (NTSC)



C-CV24-2 (PAL)









Power Source

24 V AC, 50/60 Hz, or 12 V DC













Power Consumption

2 W

















Image Device

1/4” IT-CCD















Number of Effective Pixels

768 (H) x 494 (V), 380,000 pixels



752 (H) x 582 (V), 440,000 pixels











Scanning System

2:1 interlace















Scanning Frequency

15.734 kHz (H), 59.94 Hz (V)

15.625 kHz (H), 50 Hz (V)











Monitor Output

VBS1.0 V(p-p), 75

, RCA pin jack













Video Output

VBS1.0 V(p-p), 75

, M3 screw terminal











Synchronizing System

Internal synchronization











Resolution

H: 480 lines (center), V: 350 lines



H: 470 lines (center), V: 410 lines











S/N Ratio

48 dB

















Minimum Illumination

3 lx (50 IRE)





3 lx (350 mV)











White Balance Mode

ATW

















Focal Length

f=2.0 mm – 4.0 mm

















Maximum Aperture Ratio

1:1.4 – 1.8

















Iris

Automatic iris















Angle of View

105.1º– 53.2º(H), 77.4º– 39.8º(V)











Control Switch

ON/OFF (for focus adjustment)









Other Functions

Backlight compensation, Shutter speed, iris adjustment











Shutter Speed

1/60,1/100





1/50,1/120











Operating Temperature

– 10ºC to + 50ºC















Operating Humidity

Under 90% RH (no dew condensation)









Finish

Case : ABS resin, light gray, Dome cover : Acrylic resin











Dimensions

ø118 x 97 (H) mm

















Weight

370 g

















The specifications of this camera are subject to change without notice.

Optional Products

Ceiling mounting bracket

Printed in Vietnam 1 3 3 - 1 2 - 8 7 4 - 5 E

Image 12
