38 EN

PLAYBACK Advanced Features For D.S.C. (cont.)



MENU/BRIGHT Wheel Deleting Images

VIDEO/DSC Switch (Open the LCD monitor

to access this switch.)



OFF



LA





Y



P



Lock Button













Power Switch





Display







E X I T



<D E L E T E >





DELETE Index

0 0 1

FX

0 0 2

SX

0 0 3

S

Screen

0 0 4

F 0 0 5

F

0 0 6

F



DSC MENU



Deletion











Confirmation





Screen

CANCE L

EXECUT E

Previously shot images can be deleted either one at a time or all at once.

1 Set the VIDEO/DSC Switch to “ ”, then set the

Power Switch to “ ” while pressing down the Lock Button.

•A stored image is displayed.

2 Press MENU/BRIGHT. The Menu Screen appears. Rotate it to select “ ” and press it. “DSC MENU” appears.

3 Rotate MENU/BRIGHT to select “DELETE” and press it. The Sub Menu appears.

TO SELECT AN IMAGE BY BROWSING IMAGES STORED IN MEMORY

Before doing the following, perform steps 1 through 3 above.

4 Rotate MENU/BRIGHT to select “SELECT” and press it. The DELETE Index Screen appears.

5 Rotate MENU/BRIGHT to move the green frame to the desired image that you wish to delete and press it. An

“ ” appears above the selected image.

Repeat this procedure for all images that you wish to delete.

To deselect an image, press MENU/BRIGHT again. The “ ” disappears.

6 Rotate MENU/BRIGHT upward to select “NEXT” and press it. The Deletion Confirmation Screen appears.

7 Rotate MENU/BRIGHT to select “EXECUTE” and press it. The selected images are deleted and the normal playback screen appears.

•To cancel deletion, rotate MENU/BRIGHT to select “CANCEL” and press it.

CAUTION:

Do not remove the MultiMediaCard or perform any other operation (such as turning off the camcorder) during deletion. Also, be sure to use the provided AC Power Adapter/Charger, as the MultiMediaCard may be corrupted if the battery becomes exhausted during deletion. If the MultiMediaCard becomes corrupted, initialise it. ( pg. 39)

TO DELETE ALL IMAGES

Before doing the following, perform steps 1 through 3 above.

4 Rotate MENU/BRIGHT to select “ALL” and press it. The Deletion Confirmation Screen appears.

5 Rotate MENU/BRIGHT to select “EXECUTE” and press it. All the images are deleted and the normal playback screen appears.

•To cancel deletion, rotate MENU/BRIGHT to select “CANCEL” and press it.

NOTES:

●Protected images ( pg. 37) cannot be deleted with the above operation. To delete them, remove protection first.

●Once images are deleted, they cannot be restored. Check images before deleting.
