CTRL TYPE
By inputting the wire remote port, you may set up the A, B, C or D mode.
Code | Tele | Wide | Far | Near |
|
|
|
| |
A | +6V | +6V | ||
B | +6V | +6V | ||
C | +6V | +6V | ||
D | +6V | +6V |
COMMUNICATION
You can set the
1.Select <MAIN
2. | Select each item and set appropriately. |
| W COMMUNICATION X |
| |
RS485 |
|
| |||
3. | PROTOCOL, BAUD RATE, ADDRESS : |
|
| ||
PROTOCOL | SAMSUNG | ||||
| You can manually set the protocol, baud | BAUD RATE | 9600 | ||
| rate and address. | ADDRESS | 0 | ||
English
SYSTEM INFO
You can check the system information.
1.Select <MAIN
2.The current system information is displayed.
WSYSTEM INFO X
TYPE | 4_34 ZOM_WDR_P |
PROTOCOL | SAMSUNG |
ADDRESS | 0 |
COMM. TYPE | RS485, HALF |
BAUD RATE | 9600 |
SERIAL NO. | 000000000000000 |
CAMERA VER. | v1.00_00000 |
