Power Acoustik PWM-30M instruction manual Specifications

Page 12

SPECIFICATIONS

S/N Ratio (Rated Power, 1KHz)	100dB
Distortion	0.01%

Separation (Rated Power, 1KHz)	100dB
FREQ. Response (1KHz=0dB, +/-2dB)	10Hz-35KHz
RCA Input Level	0.7-7V
RCA Input Impedance	20KΩ
HI-Level Input Level	5V
HI-Level Input Impedance	100Ω
Gain	20dB
Line Out Level (RMS.)	7V
Line Out Impedance	1KΩ
SUB-WOOFER Output Level	6V
SUB-WOOFER Output Cut-off FREQ.	30Hz - 180Hz
EQ Control Range	+/- 15dB

Power Source		9V-15V
Ground System		NEGATIVE GROUND
MAX Current		1A
Weight		1.25Kg
Dimensions (W x H x D)		178x50x180mm
	Design and specifications subject to change without notice.

Image 12
