JVC KD-LX1 CD Operations, Playing a CD, Open the loading slot, To stop play and eject the CD

Page 11

CD OPERATIONS

Playing a CD

FUNC

1

1

Open the loading slot.

The display panel moves down, and the loading slot appears.

ENGLISH

2

Insert a disc into the loading slot.

The unit draws a CD, the display panel moves up, and CD play starts automatically.

Total track number

Total playing time of

Elapsed

of the inserted disc

the inserted disc

Current track playing time

Notes:

When a CD is in the loading slot, selecting “CD” as the source by pressing FUNC starts CD play.

When a CD is inserted upside down, “CD EJECT” appears on the display and the CD automatically ejects.

When you play a CD Text, the disc title and performer appear on the display. Then the current track and elapsed playing time appears on the display. See also “Playing a CD Text” (page 12) and “To select the scroll mode” (page 26).

If a CD Text includes much text information, some may not appear on the display.

To stop play and eject the CD

Press OFF/0 briefly.

CD play stops, the display panel moves down, then the CD automatically ejects from the loading slot.

• If you change the source, the CD play also stops (without ejecting the CD this time).

To close the display panel, press ¢ or 4 .

CAUTION: NEVER insert your finger between the display panel and the unit, as it may get caught in the unit.

Note:

If the ejected disc is not removed for about 15 seconds, the disc is automatically inserted again into the loading slot to protect it from dust. (CD play will not start this time.)

11
