Page 8

Operation

Operation

To Answer Calls

Bluetooth®

Note

When cell phone calls are in progress using the Bluetooth feature, the CB functions of the unit are disabled.

Note

If no further pairing steps are taken, the unit will time-out and return to Standby after five minutes. During the pair- ing process, press and release the BT Button to can- cel the pairing process.

Bluetooth

Calls on a Bluetooth enabled cell phone can be routed through the 29 WX NW BT speaker or external speaker accessory.

C H 1 9

BT LED

Indicator



C H 9

RX/TX ANT

WX



N O R



BT Button

To Pair with a Cell Phone

1With 29 WX NW BT power On, press and hold the BT Button for six seconds to enter Standby mode. A tone will sound and the BT LED will flash for one minute to confirm entry

to Standby.

2From Standby,press and hold the BT Button for four seconds to enter Pairing mode.

A.First time pairing with a cell phone:

I.A tone will sound and the BT LED will flash rapidly to confirm Pairing mode.

II.Follow the cell phone manufacturer's instruction to enable its Bluetooth function and enter the PIN (Personal Identification Number)0000.

III.Successful pairing will be indicated by a tone and brief flashing of the BT LED to confirm entry to Connected mode.A pair record will also be established for subsequent connections.

B.Subsequent pairings with a cell phone:

I.Follow any cell phone manufacturer instructions, if needed, to enable the Bluetooth function.

II.Successful pairing will be indicated by a tone and brief flashing of the BT LED to confirm entry to Connected mode.

1Press and release the BT Button when the cell phone ring is heard through the 29 WX NW BT speaker. The BT LED will light steadily to indicate a call is in progress.

2Speak into the 29 WX NW BT microphone.The CB function of the unit and PTT Button will be disabled while a call is in

3progress.

End the call by press and release of the BT Button. A tone will sound and the BT LED will flash briefly.

To Initiate Calls

1Dial a number according to the cell phone manufacturer’s instructions. The key press and other tones will be heard through the 29 WX NW BT speaker.

2Press Send on the cell phone. The BT LED will light steadily to indicate a call is in progress; and after a few seconds, you will hear the ring tone for the number you dialed.

3Once connected, speak into the 29 WX NW BT microphone.

4End the call by press and release of the BT Button. The BT LED will flash briefly.

5Redial a number by press and hold of the BT Button for two seconds. A tone will sound; and after a few seconds, you will hear the ring tone for the number you dialed.

To Enable or Disable Voice Dialing

If the paired cell phone supports voice dialing, press and release the BT Button twice to toggle between enabling and disabling this feature.

ToTurn Off The Bluetooth Function

Press and hold the BT Button for six seconds to turn off the Bluetooth function. Two short tones will sound and the BT LED will turn Off and remain Off.

To Re-pair The 29 WX NW BT To The Cell Phone

If pairing is lost while the 29 WX NW BT power is On,press and hold the BT Button for four seconds to re-pair with the cell phone.

If the 29 WX NW BT is turned Off,it will retain the Bluetooth address and automatically re-pair with the last cell phone used when

it is turned back On.

Note

For best audio quality while using the Bluetooth feature, place your cell phone at least 12 inches away from the

29 WX NW BT.

Note

The external microphone can be plugged into the rear of the unit and clipped to a pocket or lapel for hands-free speech during calls.

When the external microphone is plugged in, the main microphone will not pick up speech during calls but will be fully functional for CB operation.

14

15
