Life Fitness OHDHR manual Step

FIGURE 10

4

13

4

12

9

10

2

1

STEP 10:

•Insert the LEFT BAR SUPPORT (12) into the desired slots of the LEFT ADJUSTMENT RACK (10), and allow it to drop down to lock in place. See FIGURE 10.

•Repeat the above step to assemble the RIGHT BAR SUPPORT (13) to the RIGHT ADJUSTMENT RACK (9).

13
