JVC A-UXP38V, SP-UXP38V manual Display Window, Pressing this button also turns on the unit

Page 7

Continued

Display Window

See pages in the parentheses for details.

English

Front Panel

1Remote sensor

2STANDBY lamp (9)

3 STANDBY/ON button (9, 14, 24) 4 TAPE 2 3 button (19 – 20)

Pressing this button also turns on the unit.

5 CD 3/8 SELECT (play/pause) button (9, 15 – 16, 18) Pressing this button also turns on the unit.

6 AHB (Active Hyper Bass) PRO button (10)

7 SOUND button (10)

8 AUX button (9 – 10)

Pressing this button also turns on the unit.

9 PHONES jack (10)

p 0 (disc tray open/close) button (12) Pressing this button also turns on the unit.

q Disc tray

w RETURN button (17) e FM/AM button (9, 11)

Pressing this button also turns on the unit. r Display window

t CLOCK button (9)

y VOLUME + / – control (10) u TIMER button (23 – 24)

i ¢ NEXT (forward search) button (9, 15 – 18) o 7 (stop) button (12, 14 – 15, 19 – 21)

; PREV 4 (reverse search) button (9, 15 – 18)

a REV.MODE (reverse mode) VCD NUMBER button (16, 20 – 21)

s Cassette holder

d REC button (20 – 21)

f 0 (eject) button for cassette deck (19 – 21)

Display Window

1Tape operation indicators

•2 3 (tape direction) and (reverse mode) indicators 2 Timer indicators

•(timer), DAILY, REC and SLEEP indicators 3 REC indicator

4 CLOCK indicator

5 CD play mode indicators

•PRGM (program), RANDOM, repeat ( /ALL) and PBC indicators

6BASS (Active Hyper Bass) indicator

7 SOUND (sound mode) indicator

8 Tuner operation indicators

•MONO and ST (stereo) indicators 9 Main display

•Shows the source name, frequency, etc.

– 4 –
