Indesit ISA60V manual Dryer Description, Front, Back, Control panel

Page 4

Dryer Description

The front

Control Panel

Model & Serial numbers

The back

Rating plate

Drum

Filter

Caution: Hot!

Air Intake Vent

Vent Tube fitted here

Control panel

Drying Guide

START

Button

HEAT

Button

Indicator

PROGRAMMES

Knob

The START button begins drying a selected programme (see Start and Programmes).

The HEAT button selects drying temperature (see Start and Programmes).

IN: HIGH heat

OUT: LOW heat

The PROGRAMMES knob sets the drying time: rotate it clockwise, never counter-clockwise, until the indicator is pointing to the programme you want (see Start and Programmes).

The Drying Guide allows you to consult a user friendly table of fabric types and load capacities.

Cotton

Synthetics

or Acrylics and other delicates

Image 4
