Philips 50PF7320/98, 37PF7320/98 Give name, Editing of channels, Name π, Channel Edit π

Page 16

2446.2 en.qxd 03-08-2006 15:32 Pagina 16

Give name

Install

Language

10

Auto Store

11

Manual Store

.........

Sort



Name π



Channel Edit

It is possible to change the name stored in the memory or to assign a name to a TV channel or external for which a name has not yet been entered. A name with up to 5 letters or numbers can be given to the programme numbers 0 to 99.

Note : It is not possible to rename the VGA source.

&Select Name in the Install menu and press the cursor right.

éSelect the programme number.

Press the cursor right.

Select the following character with the cursor up/down.

(Select the following position with the cursor right.

§Select the following character.

èPress the cursor left repeatedly when finished.

!Select another programme number and repeat steps é to

è.

çPress the MENU key to return to the TV menu. Press again to exit the TV menu.

Note: space, numbers and other characters are located between Z and A.

Editing of channels

Install

Language Channel

Auto Store Skipped

Manual Store

Sort

Name

Channel Edit π

This feature allows you to edit or skip channels from the channel list which have bad of weak signals or channels which you do not watch often.

Note: Once a channel is skipped, you cannot select it with the -P+key; you can only access the channel with the digit keys.

&Select Channel edit in the Install menu;

éPress the cursor right to enter the channel list.

Select the channel you want to skip with the cursor left/right.

Press the cursor down to select Skipped On or Off.

(Press the cursor up/down to select another channel and repeat step .

§Press the MENU key to return to the Install menu.

16
