Pioneer CDJ-1000MK3 Connecting a stereo amplifier when not using DJ mixer, Accessory control cord

Page 9

Connections

2. Control cord connections for relay play

By using the accessory control cord to connect the control connectors of two DJ CD Players, automatic relay play can be performed. (P.19)

CDJ-1000MK3

CDJ-1000MK3



Accessory control cord

3. Connecting other components

AConnecting a stereo amplifier (when not using DJ mixer)

Stereo amplifier

Connect to CD or AUX IN connectors.

(Do not connect to PHONO IN connectors.)























CDJ-1000MK3

Accessory audio cable

BConnecting a component equipped with DIGITAL IN connectors

CD recorder or amplifier with



DIGITAL IN connectors, etc.



Commercially available



coaxial digital signal cable

CDJ-1000MK3

The DIGITAL OUT connectors produce audio data only (without subcodes; CD graphics are not supported).

Depending on the CD recorder or other component connected, some recording or other functions may be limited. For details, consult the operating instructions for the connected component.

4. Connecting the power cord

After completing all other connections, connect one end of the accessory power cord to the AC inlet on the rear side of the player, and connect the other end to a standard AC wall outlet, or to the auxiliary power outlet on your amplifier.

9
