iHome iH51 manual Quick start, Always USE AN Insert to Dock Your iPod

Page 7

quick start

5:inserts 6:iPod7:radio

Select the insert that matches your iPod (see table below) and place in the universal dock.

Insert iPod into the dock (iPod must not be in a skin or case). The iPod will charge while docked. To play, press the Play Button on the iH51 to select iPod mode and play the iPod.

Press the Radio/Aux button as needed to select AM/FM band. Press the Forward or Reverse Button to tune in a station. See page 5

for programming presets.

8:time

Table 1: Selecting an Insert

Move the DST switch on back of unit to +1 or -1 (adds or subtracts an hour)

Press & hold the Time Zone button on back until the display flashes

Turn the Set Wheel to select your time zone

Press the Time Zone button again.

ALWAYS USE AN INSERT TO DOCK YOUR iPod

thin iPod with video (30 GB)

iPod with video (60,80 GB)

3rd Gen nano

iPod Touch

Insert 9



Insert 10

Insert 13

Insert 14

thin (30

GB) iPod with video

thick (60,80 GB) iPod with video

3rd Gen nano

iPod Touch

thin (80

GB) iPod classic

thick (160 GB) iPod classic





NOTE: If you do not have an insert for your model iPod, please visit an Apple store, www.ihomeaudio.com, or call iHome toll free at 800-288-2792 to purchase one

5
